JUMPER SELECTION
Jumper
S.A (Stand Alone) /BUS
J12
J13: Alarm EOL
J15: Tamper EOL
TAMPER EOL JUMPERS (J15)
NO
1K 2.2K
RESISTOR
(Default)
ALARM EOL JUMPERS (J13)
NO
1K 2.2K
RESISTOR
(Default)
Function
Used to enable tamper indication during Stand Alone
or BUS mode.
Jumpers J13 and J15 allow for the selection of Alarm
and Tamper resistance (1K, 2.2K, 4.7K, 5.6K and 6.8K)
according to the control panel. Follow the terminal block
connection diagram in Figure 4 when connecting the
detector to a Double End Of Line (DEOL) zone.
4.7K 5.6K 6.8K
4.7K 5.6K 6.8K
Figure 4: Schematic of EOL Resistors
Stand Alone mode (Default).
BUS connection mode.
(See RISCO system programming manuals).
ALARM
C NC
Panel DEOL
9
TAMPER
TAMPER
