Follett Maestro
for Remcor/Cornelius Countertop ice and beverage dispensers
Order parts online
www.follettice.com
Installation, Operation and Service Manual
Following installation, please forward this manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
™
Chewblet
Ice Machine and Top Kit
®
400 Series
00117259R07
Advertisement
Table of Contents
Related Manuals for Follett Maestro Chewblet MSC44SC
Summary of Contents for Follett Maestro Chewblet MSC44SC
- Page 1 ™ ® Follett Maestro Chewblet 400 Series Ice Machine and Top Kit for Remcor/Cornelius Countertop ice and beverage dispensers Order parts online Installation, Operation and Service Manual www.follettice.com Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
-
Page 2: Table Of Contents
Table of contents Welcome to Follett Corporation Important cautions Specifi cations Installation Cleaning/descaling and sanitizing Replacement Parts Models MTC22SC, MSC22SC Models MTC24SC, MSC24SC Models MTC30SC, MSC30SC Model MSC44SC Maestro 400 Series Top Kit for Remcor/Cornelius... -
Page 3: Welcome To Follett Corporation
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the fi ling of a claim, if necessary. -
Page 4: Specifi Cations
Separate drains for ice machine and condenser. To prevent back fl ow, do NOT connect drains. • Follett recommends a Follett water fi lter system be installed in the ice machine inlet water line (standard capacity #00130299, high capacity #00978957, carbonless high capacity #01050442). - Page 5 Dimensions and clearances Required clearances – MCD400 series Entire front of ice machine clear of obstruction/connections to allow removal. 12" (305mm) above ice machine for service 6" (153mm) minimum between louvered (exhaust) side of ice machine and any adjacent equipment. MCD400AHS –...
-
Page 6: Installation
Installation Fig. 1 Install Cornelius ice dispenser according to agitation manufacturer’s specifi cations. timer Note: We recommend that the dispenser back be mounted at least 1" (26mm) from wall to allow water, drain and electric lines from top-mount ice machines to be concealed behind dispenser. 2. - Page 7 Fig. 3 Remove existing plastic top from dispenser and install supplied gasket around perimeter of dispenser top (Fig. 3). gasket Note: Sanitize dispenser before proceeding. Fig. 4 8. Install supplied stainless steel top with access opening toward front of dispenser (Fig. 4). For dispensers with top mounted ice machines Proceed with steps 9 through 17.
- Page 8 Fig. 5 Top mounted ice machine installation 9. Position Follett MCD400AHT ice machine on perimeter gasket of stainless steel top. Ice machine should be oriented with A/C condenser facing front (Fig 5). Maestro 400 Series Top Kit for Remcor/Cornelius...
- Page 9 Power machine to install water tubing without kinking 115V tubing or putting stress on fi tting. Note: Follett recommends the installation of a Follett water fi lter system (part# 00130229) on supply water inlet. 3/8" OD water inlet Drain 3/4" MPT...
- Page 10 13. Remove ice machine top panel and louvered side Fig. 8 panel. 14. Insert ice transport tube to a 1/2" (13mm) depth through mounting bracket (Fig 8 and 9.1) and ice transport tube secure transport tube away from condenser fan under fl oat reservoir bracket (Fig.
- Page 11 RIDE model ice machine installation Fig. 10 – Single ice tube dispensers 18. Ice transport tube chase may be located behind rear entry chase or to either side of the dispenser (Fig. 10 and 11). Using the chase mounting bracket (Fig. 1.25"...
- Page 12 (Fig. 13.2). 20. Follow the “RIDE model ice machine installation procedure” found in the Symphony MCD400 Ice machine Manual 208600 to install your Follett ice machine. 21. Route the bin signal cord from the 4" x 4" (102mm x 102mm) junction box through the top knockout (Fig.
- Page 13 23. Connect the ice transport tube(s) to the dispenser: Fig. 14 a) Drill 3/16" (5mm) holes through both sides of the tube 1/2" (13mm) from the tube end. b) Collapse tube and insert through gasketed hole (Fig. 14.1). c) Match tube holes to bracket tabs. 24.
-
Page 14: Cleaning/Descaling And Sanitizing
Cleaning of the condenser can usually be performed by facility personnel. Cleaning/descaling and sanitizing of the ice machine system should be performed by your facility’s trained maintenance staff or a Follett authorized service agent. Regardless of who performs the cleaning, it is the operator’s responsibility to see that this cleaning is performed according to the schedule below. - Page 15 Clean/descale ice machine If ice machine was running recently, ensure that the evaporator is completely free of ice before proceeding. Disconnect power to ice machine. Remove any ice machine panels required to gain access to water reservoir and electrical control box. Turn compressor switch on electrical box of ice machine to OFF position.
-
Page 16: Replacement Parts
Service Replacement parts Top kit models MTC22SC, MSC22SC Reference # Description Part # Base, top mount 00113506 Base, RIDE model 00113266 Cabinet 00113324 Cover 00113357 Chase, upper 00113381 Chase, lower 00113399 Collar 00113407 Defl ector, single 501616 Lid, access 00113423 Box, thermostat 00113449 Gasket, top, Harmony... -
Page 17: Models Mtc24Sc, Msc24Sc
Top kit models MTC24SC, MSC24SC Reference # Description Part # Base, top mount 00119495 Base, RIDE model 00119487 Cabinet 00119503 Cover 00119511 Chase, upper 00113381 Chase, lower 00113399 Collar 00113407 Defl ector, single 501616 Lid, access 00113423 Box, thermostat 00113449 Gasket, top, Harmony 00113464 Gasket, ice entry... -
Page 18: Models Mtc30Sc, Msc30Sc
Top kit models MTC30SC, MSC30SC Top Kit models MRC44SC, MRC44RC Reference # Description Part # Base, top mount 00113282 Base, RIDE model 00113274 Cabinet 00113332 Cover 00113365 Chase, upper 00113381 Chase, lower 00113399 Collar 00113407 Defl ector, single 501616 Lid, access 00113423 Box, thermostat 00113449... -
Page 19: Model Msc44Sc
Top Kit models MSC44SC Reference # Description Part # Base, RIDE model 00113290 Cabinet 00113340 Cover 00113373 Chase, upper 00113381 Chase, lower 00113399 Collar 00113407 Defl ector, single 501616 Lid, access 00113423 Box, thermostat 00113449 Gasket, top, Harmony 00113464 Gasket, ice entry 502824 Socket, bin signal 502334... - Page 20 Water pressure regulator (25 psi) 501781 Harmony, Maestro, and SafeCLEAN are trademarks of Follett Corporation. Chewblet, RIDE and Follett are registered trademarks of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA 00117259R07 Toll free (877) 612-5086 • +1 (610) 252-7301 ©...
