Preparations
Checking the package contents
Please make sure that the following items are included in the box, along with the main unit.
If any item is missing, immediately contact the store where you purchased the product.
(1)
(5)
(6)
(2)
(7)
(3)
(4)
■ ■
(1) Remote control
■ ■
(2) R03 (SIZE AAA) batteries for remote
control (2)
■ ■
(3) CD-ROM
Note
The shape and number of supplied power cords vary depending on the product destination.
Save Original Packing Materials
The original shipping carton and packing materials will come in handy if you ever have to
ship your projector. For maximum protection, when shipping your projector, repack the set
as it was originally packed at the factory.
◆The Supplied CD-ROM
The supplied CD-ROM contains an owner's manual, including information not available for
the printed Owner's manual (Getting Started) in Portable Document Format (PDF). Please
use Acrobat Reader 5 or later version to view the manual.
■ Adobe
®
®
®
Acrobat
Reader
or Adobe
The supplied CD-ROM does not contain Acrobat
files, please install Adobe Reader software in your computer by downloading it from the
Adobe Systems website.
■ Viewing the manual
Run the CD-ROM and double-click on Start.pdf. Acrobat
menu screen of the Owner's manual appears. Click on your language. The Owner's
Manual cover and list of bookmarks appear. Click on a bookmark title to view that
section of the manual. Click on
to view a reference page with related information.
p.
See the Help menu for more information about Acrobat
■ ■
(4) Owner's Manual (This document)
■ ■
(5) RGB cable (3m)
■ ■
(See note below)
(6) Power cord
■ ■
(7) Carrying bag
®
®
Reader
®
Reader
®
. If you cannot read PDF
®
Reader
®
launches, and the
®
Reader
®
.
14
Names of each part on the main unit
(4)
(8)
(5)(6)
(10)
(9)
(7)
Back
Name
: Function
(1) Infrared remote sensor
: Senses commands from the remote control.
(2) Foot adjuster release button : Press to set up or stow the foot adjuster.
(3) Air intake
: Draws in air from outside the projector.
(4) Control panel
: Operates the projector.
(5) Zooming lever
: Adjusts screen size.
(6) Focusing ring
: Adjusts screen focus.
(7) Antitheft lock slot
: Attach a safety cable or any other antitheft device.
(8) Speaker
: Outputs audio sound.
(9) Terminals on the rear panel
: Connects external devices.
(10) AC IN socket
: Connect the supplied power cord here.
(11) Air exhaust
: Expels air that has grown hot inside the projector.
(12) Tilt adjuster
: Adjusts the projector's horizontal tilt.
(13) Lamp cover
: Remove to replace lamp.
(14) Foot adjuster
: Adjusts the vertical projection angle.
(15) Air filter
: Prevents dirt and garbage from getting into the inside
of the projector.
(16) Lens
: Projects expanded image.
(3) (2)(16)(1)
(12)
(13)
(11)
(12)
(14)
(15)
Front
p.19
p.26
p.16
p.26
p.26
p.18
p.26
p.44
p.26
15
