rev 2
SyStem One IntercOm SyStemS
QUICK START GUIDE
For Installers

Advertisement

loading
Need help?

Need help?

Do you have a question about the iCentral System One and is the answer not in the manual?

Questions and answers

Related Manuals for Ness iCentral System One

Summary of Contents for Ness iCentral System One

  • Page 1 rev 2 SyStem One IntercOm SyStemS QUICK START GUIDE For Installers...
  • Page 2 8 wIre cOnnectIOn OvervIew 8 wIre metHOd cat5 cat5 cat5 cat5 rG59* 13.8vdc Input Optional 12v relay FIG8 14/020 101-283 FIG8 14/020 Optional 12v door strike 840-015 13.8vdc 5a Switch mode Power Supply (Sold separately) *rG59 coax cable for video door stations. Or see page xx ‘video via 6 wire cable’ this diagram is an overview of required cabling, not a wiring diagram.
  • Page 3 8 wIre  8 wire connection  mASTER To Room STATIonS using cat5                            ...

  • Page 4: Wire Connection

    8 wIre 8 wire connection  mASTER To DooR STATIon  using cat5 and rG59/rG6                          ...
  • Page 5 8 wIre 6 wIre BalancInG reSIStOr  On Room Station only systems (without a master), a 22K load resistor is required and must  be fitted across the vlc and neG terminals of the room Station to which the power supply is connected.
  • Page 6 8 wIre 6 wIre                           System One Intercom QuIck Start GuIde...
  • Page 7 6 wIre 300 Ohm Ribbon FM Dipole 6CORE AM Loop RG59 Antenna 840-015 13.8v 5a Switch mode power supply (Power Suppy sold separately) System One Intercom QuIck Start GuIde...
  • Page 8 6 wIre   13.8V P/S    13.8V BLACK GREEN ORANGE WHITE COM1 COM1 BLUE COM2 COM2 2 X WIRE LINKS* MUS1 MUS1 MUS2 MUS2 *2 X WIRE LINKS ARE FITTED AT MASTER ONLY System One Intercom QuIck Start GuIde...
  • Page 9 6 wIre   13.8V P/S    13.8V BLACK ORANGE VLC1 WHITE COM1 COM1 BLUE COM2 COM2 MUS1 CH– MUS2 LK– TC WIRE ELININATOR GREEN VID1 VSIG GND1 VSHLD Notes: It is important to strictly adhere to the above format for optimum performance Cable Requirement: 1 x 6Core Cable (for intercom and video operation) 1 x TC Wire Eliminator Module (P/N: 110001)
  • Page 10 6 wIre   13.8V P/S    13.8V BLACK ORANGE VLC1 WHITE COM1 COM1 COM2 COM2 MUS1 CH– MUS2 LK– TC WIRE ELININATOR BLUE VID1 VSIG GREEN GND1 VSHLD Notes: It is important to strictly adhere to the above format for optimum performance Cable Requirement: 1 x 6Core Cable (for intercom and video operation) 1 x TC Wire Eliminator Module (P/N: 110001)

  • Page 11: Am Loop Antenna

    6 wIre  FM 300 OHM RIBBON ANTENNA AM LOOP ANTENNA RG59 OUTER SHIELD CENTRE CORE CONNECTION AT MASTER System One Intercom QuIck Start GuIde...
  • Page 12 6 wIre PROGRAMMING All stations need to be programmed to “6Wire” mode. For the purpose of calling individual (or groups of) stations, stations can be programmed to different numbers (from 1 to 7) All stations including master are programmed to #1 by default. To program the master station: Press PRIV and MON buttons at the same time to enter program mode ...
  • Page 13 6 wIre 6 wIre OPeratIOn HOw It wOrkS • Programming for 6-wire is required to shift functions associated with the music wires to the intercom wires. • The master station and each individual room station have to be programmed for 6 wire. •...
