Installation Notes
Ness radIO dIaLLer
Part No. 100-284
Hybrid Wireless/Landline dialler for Ness securityGuard systems
Features
•
supervised radio link to securityGuard
•
Onboard backup battery
•
Mains Fail supervision and warning
•
Low Battery / Battery Missing / Battery
Capacity tests and warning
•
telephone Line supervision
•
Fast & easy installation
•
No special tools required
•
Compatible with securityGuard II & III
Advertisement
Table of Contents
Related Manuals for Ness 100-284
Summary of Contents for Ness 100-284
- Page 1 Installation Notes Ness radIO dIaLLer Part No. 100-284 Hybrid Wireless/Landline dialler for Ness securityGuard systems Features • supervised radio link to securityGuard • Onboard backup battery • Mains Fail supervision and warning • Low Battery / Battery Missing / Battery Capacity tests and warning •...
- Page 2 II (sGII) can easily be retro- fitted with the optional radio interface. the Ness radio dialler is designed to easily plug into an existing telephone wall socket and does not need to be installed by a licensed telecommunications cabler.
- Page 3 Telephone connection the Ness radio dialler should be connects to an existing telephone wall socket, preferably the first incoming telephone socket. the existing telephone’s lead connects to the radio dialler’s LINe socket and the supplied telephone cable is used to connect the radio dialler to the existing telephone.
- Page 4 7. On power-up, the indicator lights will briefly Programming & Setup (SGIII) flash out the software version number. “One shot” Programming downloads programming the MaINs ON light will be on and the radIO data from the sGIII to the radio dialler and LINK light will double-flash.
- Page 5 Front Panel Indicators the front panel indicators (Leds) are used to indicate the status of various radio dialler conditions. On: Mains is ok On: receiving a valid programming message such as the Learn message from an sGIII. FlaShInG: Mains has been off for at least one hour.
- Page 6 PC and Ness upload/download software. dial tone. remote programming can used either to: In cases where the dial tone is undetectable or...
- Page 7 Contact ID Reporting Codes MeSSaGe FORM the Contact Id message is reported in the following format: ssss 18 Q XYZ GG CCC e ssss 4 digit Client account number uniquely identifies this format as Contact Id event qualifier (1 = New alarm or Open; 3 = restore or Close) event code (hexadecimal) Group code.
- Page 8 Ness. Ness reserves the right to make changes to features and specifications at any time without prior notification in the interest of ongoing product development and improvement.
