- Page 1 Ness Smartbell IP Intercom Turn your iPhone/Smart phone/Tablet into Video & Audio Intercom Quick Start Guide Ness SmartBell IP Intercom Quick Start Guide...
-
Page 2: System Diagram
System Diagram Ness SmartBell IP Intercom Quick Start Guide... -
Page 3: Setting Up The Egateway For The First Time
Open a web browser such as Internet Explorer and enter in 192.168.0.10 then press enter. When prompt for a username and password enter in: Username: admin Password: admin 3. Once logged in, select Settings > LAN from the side menu. Ness SmartBell IP Intercom Quick Start Guide... - Page 4 6. Re-open your web browser and enter in the IP address you set in step 4. (You should still have the LAN cable plugged into LAN1 that is connected to your computer) 7. Once logged in, select Settings > WAN from the side menu. Ness SmartBell IP Intercom Quick Start Guide...
- Page 5 Now the eGateway has been setup and ready for new devices to be paired and setup. From now on, you only connect using the WAN port (blue port) and the IP address you set in step 8. Ness SmartBell IP Intercom Quick Start Guide...
-
Page 6: Pairing The Outdoor Phone To The Egateway
Once the unit is paired click on the tick box next to your ODP and click Edit Enter a name for your ODP (such as Front Door) and press the Save button. Note: Do not change other settings on this page. Ness SmartBell IP Intercom Quick Start Guide... - Page 7 Please fill in the range of 100 to 109 ensuring this number is not registered Password Can be re-configured according to individual needs, or left as assigned by the eGateway. Press the Save button Then click Start Pairing Ness SmartBell IP Intercom Quick Start Guide...
- Page 8 To complete the ‘Pairing’ process, click on the Save button in the eGateway’s web GUI to finish pairing. Once successfully registered click “Homepage” on the Tablet and ‘Unit Pairing’ tab on the web GUI of the eGateway which should now show ‘connected’. Ness SmartBell IP Intercom Quick Start Guide...
-
Page 9: Pairing A Android Device To The Egateway
Select Smart Phone Type Account Please fill in the range of 100 to 109 ensuring this number is not registered Password Enter in a password. Press the Save button Then click Start Pairing Ness SmartBell IP Intercom Quick Start Guide... - Page 10 You can get this by typing in ‘What is my IP’ into Google. 8. Once the items have been filled in press the Registration button. 9. Once the pairing is complete, press the save button in the web GUI. Ness SmartBell IP Intercom Quick Start Guide...
-
Page 11: Pairing A Ios Smart Device To The Egateway
Select Smart Phone Type Account Please fill in the range of 100 to 109 ensuring this number is not registered Password Enter in a password. Press the Save button Then click Start Pairing Ness SmartBell IP Intercom Quick Start Guide... - Page 12 6. On your iDevice (iPhone/iPad) tap on the Settings icon from the home screen. 7. Scroll down the list into you find Ness Smartbell and tap on it. 8. Fill out the following items Name Enter Account (100-109) as per the pairing screen in the eGateway.
- Page 13 9. Once the items have been filled in press the Home button on the smart device 10. Find the Ness Smartbell app icon on the home screen and tap on it. 11. Once the app has opened and it’s connected, press the save button in the web GUI.
- Page 14 Notes Ness SmartBell IP Intercom Quick Start Guide...
- Page 15 Notes Ness SmartBell IP Intercom Quick Start Guide...
- Page 16 Brisbane Office - (07) 3399 4910 Perth Office -(08) 9328 2511 Adelaide Office - (08) 8277 7255 Support Email customerservice@ness.com.au Phone 1300 551 991 (Within Australia) +61 2 8825 9222 (Outside Australia) Online www.youtube.com/nesscorporation Ness SmartBell IP Intercom Quick Start Guide...
