Figure 2 CoreBuilder 9000 Enterprise Switch 16-slot Chassis
R
1 2
Unless otherwise noted, the same installation procedures apply to both
the CoreBuilder 9000 8-slot chassis and the 16-slot chassis.
For additional chassis preinstallation information, see Appendix B in the
CoreBuilder 9000 Enterprise Switch Getting Started Guide.
Chassis Quick Installation Guide
Interface Switch fabric
module module
slots slots
3 4 5 6 7 8 9 10
Power supply slots
Interface
module
slots
®
CoreBuilder 9000
11 12 13 14 15 16
Management
module slots
