7 While the 8-slot chassis or the 16-slot chassis is still in the base of the
shipping box, have one person grasp the chassis and tilt the chassis
backward.
8 To make chassis installation easier, remove another blank faceplate from a
power supply slot.
a While the 8-slot chassis is in this position, and using a flat-blade
screwdriver, remove the blank faceplate from power supply slot 3 only.
See Figure 6.
b While the 16-slot chassis is in this position, and using a flat-blade
screwdriver, remove the blank faceplate from power supply slot 4 only.
Power supply slots are numbered one through four, from left to right
(Figure 7).
9 Using two people, lift the CoreBuilder 9000 8-slot chassis or 16-slot
chassis out of the shipping box base and place the chassis on the floor in
front of the rack, table, or shelf that you plan to use.
To help you hold onto the 8-slot chassis when you lift it, you can place
one hand into the empty power supply slot 3. The other person places
one hand into empty power supply slot 1.
To help you hold onto the 16-slot chassis when you lift it, you can
place one hand into the empty power supply slot 4. The other person
places one hand into empty power supply slot 1.
10 Inspect the chassis for damage. If the chassis appears to be damaged,
repack it in the shipping box and contact your local supplier.
The shipping box is reusable; place all packing materials in the chassis
shipping box and store the shipping box for future use.
