2.2
Charger socket
This socket should only be used for charging or locking the wheelchair. Do not
connect any type of programming cable into this socket. This socket should
not be used as a power supply for any other electrical device. Connecting
other electrical devices may damage the control system or affect the
wheelchair's EMC (electromagnetic compatibility) performance.
IMPORTANT! Use only the supplied battery charger
2.3
Function buttons
The control panel has a total of 9 function buttons and a joystick.
2.3.1
On/off button
The on/off button turns on or off the wheelchair.
2.3.2
Horn button
The horn will sound while this button is pressed.
Joystick panel, R-net LED control panel - 7
