2.4

Battery voltage indicator

The display shows battery status (from left to right):
Red, yellow and green
Red and yellow
Red
The battery voltage indicator does not show exactly how much charge is left
in the battery, but it provides a rough idea to help you avoid unnecessary
stops due to discharged batteries.
The indicator shows a more precise value about one minute after you stop
driving and are no longer using any power functions.
The battery voltage indicator also functions as a fault indicator for the
wheelchair's electronics.
Fully charged
Half charged
Charge the batteries
Joystick panel, R-net LED control panel - 11
