Lumineux Hurworth 3CCT Quick Start Manual

Hurworth
3CCT
Wallpack
1
READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
4
BOX CONTENTS
This lighting fi xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
luminaire to confi rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the fi xture
or any of its components.
• Light Fitting
• Instruction Manual
7
• Fixings
TOOLS REQUIRED
• Drill
• Screwdriver
• Cable
A
F F Manby Business Park, Manby, Lincolnshire, LN11 8UT
G Lumineux is a B&T Associates Ltd company.
INSTALLATION INSTRUCTIONS
2
on
off
5
8
Battery
Emergency
Converter
Technical Helpline: +44 (0)1507 328031
30W
≤85
5 YR
IP65 3CCT
Lm/W Warranty
3
6
Electrical connection wiring
NEUTRAL = Blue
EARTH = Green/Yellow
1. Unscrew the 7 screws securing the diffuser
LIVE (SW) = Brown
2. Drill the required mounting points in the base
3. Mark and Drill holes into the mounting surface
4. Secure the fi xture in place. Note: If protection
9
5. Install the supplied cable gland to
6. Thread cable through gland and wire as
on
7. Tighten the cable gland
8. Connect Battery (Emergency versions only)
9. Secure diffuser into position and then
off
Hurworth
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
against ingress of moisture is required, the
heads of screws must be covered with a
water resistant sealant
required position
per diagram on left, for emergency, please
refer to reverse page
re-connect the mains supply
www.lumineux.co.uk
