Push【M】Button again when the touch screen is in main menu interface and touch
screen will enter 4-screen input source preview.
Turn on【Viewfinder】, you can see a white rectangle in the Preview as shown in the
picture, helping users frame the camera view.
The 【LCD Info】is LCD display setting, which controls whether the 2x2 video
preview is 【simple】or as 【standard (Preview)】, turn on【LCD Info】to check
the resolution of four inputs as shown in the picture below:
Turn on
Standard
Simple
3.6.2 USB Output
USB output recognized as WEBCAM on computer defaults to be PGM Program which
can be changed to PVW multi-view Preview or TP (Test Pattern).
Push【M】Button to return main menu and find【Output】to do WEBCAM setting.
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
28
