M-system M6DXF2 Instruction Manual page 3

■ CONNECTION DIAGRAM
+ 1
INPUT 1
– 2
+ 3
INPUT 2
– 4
JACK
CONFIGURATOR
■ WIRING INSTRUCTIONS
• Applicable wire size
Solid: 0.2 to 2.5 mm
Stranded: 0.2 to 2.5 mm
cause contact failure and therefore is not
recommended.)
Ferruled: 0.2 to 1.5 mm
• Expose wire conductors by 8 mm (0.31").
Wire exposure
8 mm
5 +
OUTPUT
6 –
7 +
POWER
8 –
POWER
(0.55 to 1.75 dia.)
2
(Tinning wire ends may
2
(0.55 to 1.35 dia.)
2
Recommended
ferruled wire
8 mm
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
• How to Connect Wires
Wire
Insert a wire. Confirm that the wire tip hits the bottom and
tighten the screw with a screwdriver.
Confirm that the wire's insulation tube is not caught in the
terminal. (Torque: 0.3 N·m)
Wire
M6DXF2
Screwdriver
Screwdriver
EM-7848 Rev.3 P. 3 / 5
