Vision+ SE
User Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vision+ SE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telycam Vision+ SE

Summary of Contents for Telycam Vision+ SE

  • Page 1 Vision+ SE User Manual V1.0...

  • Page 2: Table Of Contents

    〓〓〓〓〓〓 CONTENT 〓〓〓〓〓〓 CONTENT ......................1 SAFETY GUIDES .................... 2 USE CHECK ....................4 PRODUCT HIGHLIGHTS ................6 CAMERA SPEC ....................7 INTERFACE DESCRIPTION ................9 CAMERA DIMENSION ................10 INSTALLATION .................... 11 IR REMOTE CONTROLLER ................ 13 VISCA IN(RS232 PORT) ................15 VISCA PROTOCOL ..................

  • Page 3: Safety Guides

    〓〓〓〓〓 SAFETY GUIDES 〓〓〓〓〓 ● Before operation, please fully read and follow all instructions in the manual. For your safety, always keep this manual with the camera. ● The camera power voltage is 12V DC, rated currency is 2A. We suggest you use it with the original power supply adapter supplied by the factory.
  • Page 4 〓〓〓〓〓 SAFETY GUIDES 〓〓〓〓〓 Attention！ ▲ The video quality may be affected by the specific frequencies of electromagnetic field. ▲ Never grasp the head of the camera, and never move the camera by hand when it is working, otherwise, mechanism maybe destroyed. Declaration：...

  • Page 5: Use Check

    〓〓〓〓〓〓 USE CHECK 〓〓〓〓〓〓 PACKING LIST Check all below items when open the package Camera · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1PCS Power Adapter ·...
  • Page 6 〓〓〓〓〓〓 USE CHECK 〓〓〓〓〓〓 Dial Switch Setting (at the bottom of the camera) Dial Switch (ARM) SW-1 SW-2 Instruction Upgrading mode Debugging mode Undefined Working mode Dial Switch SW-3 SW-4 Instruction Reserved Reserved Reserved Reserved Dial Switch SW-5 SW-6 Instruction Undefined Working mode Undefined...

  • Page 7: Product Highlights

    〓〓〓 PRODUCT HIGHLIGHTS 〓〓〓 ★ Adopting the most advanced image processing DSP, 1/2.8 inch 8.42MP sensor. ★ 4K wide angle optical lens: 12x optical zoom, with 80.5 degree field of view. ★ IP(NDI ® |HX) Ultra HD 4K60 video output, while supporting H.264, H.265 encoding.

  • Page 8: Camera Spec

    〓〓〓〓〓 CAMERA SPEC 〓〓〓〓〓 Vision+ SE Sensor 1/2.8inch high quality、8.42 MP CMOS Sensor TLC-300-IP-12-4K(NDI)-AB-SE- TLC-300-IP-12-4K(NDI)-AB-SE- Part no. HDMI HDMI: 3G-SDI： 3840*2160P15~60; 1080P60/50/30/25/59.94/29.97/24/23.98 1920*1080P15~60; 1080160/50/59.94; 1280*720P15~60; 720P60/50/30/25/59.94/29.97 1024*576P15~60; MJPG, H.264: Video Format 3840*2160P30; 1920*1080P30; 1280*720P30;1024*576P30; 800*448P30 NV12: 1920*1080P10; 1280*720P25; 1024*576P30; 800*448P30 3840*2160P15~60;1920*1080P15~60;...
  • Page 9 〓〓〓〓〓 CAMERA SPEC 〓〓〓〓〓 HTTP, RTSP, RTMP, Onvif, Visca TCP, Visca UDP, Visca over IP, NDI ® |HX, Protocol Visca Serial, Pelco-P, Pelco-D POE+ Supported Daisy Chain Support RS232 serial daisy chain Minimum Lux 0.5lux White Balance Auto / Manual / ATW / Push / Indoor / Outdoor / Color Temperature Exposure Auto / Manual /Shutter / Iris / Bright Focus...

  • Page 10: Interface Description

    〓〓 INTERFACE DESCRIPTION 〓〓 1.Camera Lens 6.Tripod Screw Hole 11.USB Type-C port 2.Camera Base 7.Installation Hole 12.HDMI port (optional) 3.IR Receiver Panel 8.RS232 ((IN) port 13.3G-SDI port (optional) 4.Power Indicator Light 9.RS232 (OUT) port 14.RJ45(NDI ® |HX) port 5.Dial Switch 10.Line in port 15.DC 12V plug —...

  • Page 11: Camera Dimension

    〓〓〓〓 CAMERA DIMENSION 〓〓〓〓 — 10 —...

  • Page 12: Installation

    〓〓〓〓〓 INSTALLATION 〓〓〓〓〓 Wall-Mount Installation: 1.Drill the hole on the wall referring to the wall mounting bracket hole position, hole diameter of φ6mm, position the four φ6mm plastic expansion screws in the drilled hole. 2.Use four M4*30 self-tapping screws to mount the wall-mount bracket on the wall.
  • Page 13 〓〓〓〓〓 INSTALLATION 〓〓〓〓〓 Ceiling-Mount Installation ： 1.Referring to the position of the cover plate holes on the bracket in the concrete ceiling, drill a hole of φ6, and position 3 plastic expansion screws of φ6 in the hole. 2.Use three M4*30 self-tapping screws to mount the bracket the upper cover plate on the ceiling.

  • Page 14: Ir Remote Controller

    〓〓〓 VISCA IN (RS232 PORT) 〓〓〓 POWER Short press POWER key to enter standby mode from normal working mode. Press it again, the camera will do self-checking, then go back to HOME position. It will go to preset position if power on mode has been set before. FREEZE Short press FREEZE key to freeze/unfreeze the image.
  • Page 15 〓〓〓 VISCA IN (RS232 PORT) 〓〓〓 FOCUS KEY: +/- Manual focus, only valid under manual focus mode. ZOOM KEY: +/- Set the Zoom rate. NAVIGATE KEY：UP/DOWN/LEFT/RIGHT Under working mode, use navigate key to set the pan tilt, and select menu when enter OSD. OK/ HOME KEY：Under working mode, short press OK to make the camera go back to HOME position;...

  • Page 16: Visca In(Rs232 Port)

    〓〓〓 VISCA IN (RS232 PORT) 〓〓〓 V_IN V_OUT V_IN RS485 A(+) B(-) VISCA IN 与 Mini DIN VISCA IN 与 DB9 Connection Connection CameraVISCA IN Windows DB-9 Camera VISCA IN Mini DIN A(+) A(+) IR OUT IR OUT B(-) B(-) —...
  • Page 17 〓〓〓 VISCA IN (RS232 PORT) 〓〓〓 VISCA Network Construction： SERIAL PORT CONFIGURATION： Parameter Value Baud rate 2400/4800/9600/115200 Start bit 1bit Date bit 8bits Stop bit 1bit Check bit None — 16 —...

  • Page 18: Visca Protocol

    〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Part1 Camera Return Command Ack/Completion Message command Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. Error Messages command Note Returned when the command format is different or when a Syntax Error z0 60 02 FF command with illegal command parameters is accepted.
  • Page 19 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command Direct 8x 01 04 46 0p 0q 0r 0s FF Enable In separate mode Stop 8x 01 04 08 00 FF Far(Standard) 8x 01 04 08 02 FF Near(Standard) 8x 01 04 08 03 FF Far (Variable) 8x 01 04 08 2p FF p=0 (Low) to 7 (High)
  • Page 20 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command Reset 8x 01 04 0A 00 FF 8x 01 04 0A 02 FF Shutter Setting CAM_Shutter Down 8x 01 04 0A 03 FF pq: Shutter Position Direct 8x 01 04 4A 00 00 0p 0q FF (0~0x15) Reset 8x 01 04 0B 00 FF...
  • Page 21 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command Reset 8x 01 04 3F 00 pp FF pp: Preset Number(=0 to 8x 01 04 3F 01 pp FF CAM_Memory(preset) 127) Recall 8x 01 04 3F 02 pp FF Reset 8x 01 04 3F 00 0p 0p FF pp: Preset Number(=0 to CAM_MemoryH 255)
  • Page 22 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command CAM_Preset Zoom Preset Zoom qq:Preset Zoom Speed 81 01 7E 01 2B 00 qq FF Speed Set Speed Set 01~07 default:5 Preset Speed p: Adjustment of direction CAM_Preset Speed Adj 8x 01 7E 01 1B 0p FF 3=down, 2=up CAM_IR address IR address...
  • Page 23 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command 0p：0x01-ON 0x00-OFF 0q：0x01-line in rstu：samplerate 8x 01 04 D8 0p 0q 0r 0s 0t 0u mn： volume 0~100 CAM_AudioSet Direct 0m 0n 0h 0i 0j FF h： encode mode 4：LPCM 5: ACC ij：...
  • Page 24 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command pq: Video format 1080P60 0x2e 1080P50 0x2f 1080I60 0x01 1080I50 0x04 1080P30 0x06 1080P25 0x08 720P60 0x09 720P50 0x0c 720P30 0x0e 720P25 0x11 1080P5994 0x13 Video System Set(Sony) 8x 01 04 24 72 0p 0q FF 1080I5994 0x02 1080P2997...
  • Page 25 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command Frame rate: 0xpq Frame Rate 8x 01 04 C2 03 0p 0q FF (15~60) IDR Setting: 0xpq 8x 01 04 C2 04 0p 0q FF (1~120) Contor mode: 0xpq Stream Rate 8x 01 04 C2 05 0p 0q FF 0x00: CBR Mode 0x01: VBR...
  • Page 26 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type function command Down Right 8x 01 06 01 VV WW 02 02 FF Stop 8x 01 06 01 VV WW 03 03 FF Absolute 8x 01 06 02 VV WW 0Y 0Y 0Y Position 0Y 0Z 0Z 0Z 0Z FF Relative 8x 01 06 03 VV WW 0Y 0Y 0Y...
  • Page 27 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type command return note CAM_RGain Inq 8x 09 04 43 FF y0 50 00 00 0p 0q FF pq: R Gain CAM_BGain Inq 8x 09 04 44 FF y0 50 00 00 0p 0q FF pq: B Gain CAM_Saturation Inq 8x 09 04 A1 FF...
  • Page 28 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type command return note CAM_ID Inq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID CAM_DHCP Inq 8x 09 04 AE FF y0 50 pp FF y0 50 0p 0p 0q 0q 0r 0r 0s 0s CAM_IP Inq 8x 09 04 AB FF y0 50 0p 0p 0q 0q 0r 0r 0s 0s...
  • Page 29 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type command return note CAM_AT_ZoomLock_In 8x 09 04 D6 FF y0 50 0p FF p: 1=Enable 0=Disable CAM_AT_LimitEnable_I 8x 09 04 D7 FF y0 50 0p FF p: 1=Enable 0=Disable 0p：0x01-ON 0x00-OFF 0q：0x01-line in rstu：samplerate 8x 01 04 D8 0p 0q 0r 0s 0t CAM_AudioSet 8x 09 04 D8 FF...
  • Page 30 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 Command type command return note Contor mode:0xpp Main Stream Rate Mode 8x 09 04 C2 05 y0 50 pp FF 0x00: CBR 0x01: VBR pqrs : Column(x size) Sub stream Resolution 8x 09 04 C3 00 y0 50 0p 0q 0r 0s 0m 0n 0x mnxy: Line (y size) 0y FF...
  • Page 31 〓〓〓〓 VISCA PROTOCOL 〓〓〓〓 VISCA PAN TILT ABSOLUTE POSITION VALUE PAN ANGLE VISCA value TILT ANGLE VISCA value -170 0xF670 0xFE50 -135 0xF868 0x0000 0xFAF0 0x01B0 0xFD78 0x0360 0x0000 0x510 0x0288 0x0510 0x0798 0x0990 VISCA PAN TILT SPEED VALUE Pan(Degree/Second) Tilt(Degree/Second) —...

  • Page 32: Pelco-D Protocol

    〓〓〓〓 PELCO-D PROTOCOL 〓〓〓〓 Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00 0x02...

  • Page 33: Pelco-P Protocol

    〓〓〓〓 PELCO-P PROTOCOL 〓〓〓〓 Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 Tilt 0Xa0 Address 0x00 0x08 Pan Speed 0Xaf Speed Tilt Down 0Xa0 Address 0x00 0x10 Pan Speed 0Xaf Speed Tilt Left 0Xa0 Address 0x00 0x04 Pan Speed 0Xaf Speed Tilt...

  • Page 34: Osd Menu

    〓〓〓〓〓〓 OSD MENU 〓〓〓〓〓〓 1. Under working mode, press the MENU key on the IR remote controller, to enter the OSD menu as below: 2. After entering the main menu, use the navigate UP/DOWN key to select the main menu. Once selected, the main menu will change to the blue background, and the right side will show sub-menu options.
  • Page 35 〓〓〓〓〓〓 OSD MENU 〓〓〓〓〓〓 AUTO、MANUAL、SHUTTER、 EXPOSURE Default: AUTO MODE IRIS、BRIGHT Shutter speed: 1/30~1/10000, only valid SHUTTER Default: AUTO under MANUAL and SHUTTER mode Iris setting: CLOSE~F1.8, only valid IRIS Default: AUTO under MANUAL and IRIS mode Gain setting: 0dB~30dB, only valid GAIN Default: AUTO under MANUAL mode...
  • Page 36 〓〓〓〓〓〓 OSD MENU 〓〓〓〓〓〓 CONTRAST Set contrast level: 0~15 Default: 8 SATURATION Set saturation level: 0~15 Default: 8 GAMMA Select gamma level: 0~15 Default: 8 IMAGE STYLE USER, NORMAL, COLORFULL Default: USER FOCUS HIGH, NORMAL, LOW Default: NORMAL SENSITIVITY SPEED BY ZOOM Optional: OFF, ON Default: ON FLIP...
  • Page 37 〓〓〓〓〓〓 OSD MENU 〓〓〓〓〓〓 IR ADDRESS Camera IR control address CLIENT VISCA MODEL NO. Model number INFO RMATIONS ARM VERSION ARM firmware version ISP VERSION Camera ISP firmware version RELEASE DATE Software release date Set IP Address in Menu In order to help customers debug, the camera has the support menu to set the IP address.

  • Page 38: Uvc Control

    〓〓〓〓〓 UVC CONTROL 〓〓〓〓〓 1. Only run the client’s software after the camera has completed self-configuration (the IR indicator in blue color and will not flash); otherwise may cause black screen issue. 2. Make sure the camera is recognized by the PC Device Manager. 3.

  • Page 39: Web Setting

    〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 It is not necessary to install additional video player plug-in to preview the local screen on the web interface. The web interface supports Google Chrome, Firefox, IE, Safari, Opera, 360, QQ and other browsers, adaptability is very good. 1.
  • Page 40 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 preview interface is displayed on the left, and the functions of camera pan tilt rotation, zoom, focus, and preset position settings can be controlled on the right. Additionally, parameters such as pan tilt and zoom speed can be set through the scroll bar.
  • Page 41 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 The "Image" option includes settings such as saturation, contrast, sharpness, brightness, backlight compensation, wide dynamic, 2D noise reduction, 3D noise reduction, gamma, etc., as shown in the following figure: The "Video" option includes settings such as output mode, VI frame rate, digital output, mirror, flip, and digital zoom, as shown in the following figure: The "Auto Tracking"...
  • Page 42 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 4. IP Settings Click on the "IP Settings" option to enter the camera IP settings interface, as shown in the following figure: The "Video Encoding" option includes settings such as main and sub stream enable, encoding mode, profile, resolution, bit rate, frame rate, bit rate control, I frame interval, RTSP address, etc., as shown in the following figure: The "Audio Settings"...
  • Page 43 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 switch, port, latency, encryption switch, etc., as shown in the following figure: The "RTMP Settings" option includes enable switches and RTMP address settings, as shown in the following figure: The "RTP multicast" option includes settings such as enable switch, multicast IP, multicast port, RTSP address, RTP address, etc., as shown in the following figure: The "NDI | HX3"...
  • Page 44 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 The "Reset Options" option includes settings such as reset, reset/reboot, reboot, and parameter batch configuration, as shown in the following figure: The "Ethernet" option includes parameters such as automatic allocation switch, IP address, net mask, gateway, HTTP port, RTSP port, Visca over IP port, RTSP encryption, etc., as shown in the following figure: 5.
  • Page 45 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 The "Firmware Upgrade" option allows you to view the device name, camera software and hardware version number, and upgrade the camera program through the "Select File" column, as shown in the following figure: The "Account Settings" option allows you to set the login account and password for the camera: The "Time Settings"...
  • Page 46 〓〓〓〓〓 WEB SETTING 〓〓〓〓〓 6. Logout Click "Logout" to return to the login interface. — 45 —...

  • Page 47: View Rtsp Video Via Vlc

    〓〓 VIEW RTSP VIDEO VIA VLC 〓〓 Default RTSP main streaming address: rtsp://192.168.1.188/stream/main Default RTSP sub streaming address: rtsp://192.168.1.188/stream/sub Default RTMP main streaming address: rtmp://192.168.1.188:1935/app/rtmpstream0 Default RTMP sub streaming address: rtmp://192.168.1.188:1935/app/rtmpstream1 1. Run VLC Media Player. 2. Media->network stream, to enter into “open media” interface. 3.

  • Page 48: Ndi Tools

    〓〓〓〓〓 NDI Tools Guide 〓〓〓〓〓 1. Image Preview https://ndi.tv/tools/ A. Download the NDI Tools via and install it. B. Find out the NDI 5 Tools/Studio Monitor via Windows toolbars, and then open it, as bellow: C. Right click on the Studio Monitor screen, select the preview device: 2.
  • Page 49 〓〓〓〓〓 NDI Tools Guide 〓〓〓〓〓 Refer to above picture, once open the video via Studio Monitor, there will show up a setting icon at the lower right corner, single click this iron to enter WEB UI. 4. How to use NDI tools to Virtual Input CAMERA A.

  • Page 50: Visca Over Ip

    〓〓〓〓〓〓 VISCA over IP 〓〓〓〓〓〓 VISCA over IP： VISCA over IP means VISCA protocol transmit via IP, to reduce RS232/RS485 cable layout (the controller must support IP communication function) Communication port spec: ⚫ Control port: RJ45 Gigabit LAN ⚫ IP protocol: IPv4 ⚫...
  • Page 51 〓〓〓〓〓〓 VISCA over IP 〓〓〓〓〓〓 Note: LAN output way is big-endian, LSB is in the front. Payload type: Data definition as following: Value Value Name Value (Byte 0) (Byte1) VISCA command 0x01 0x00 Stores the VISCA command. VISCA inquiry 0x01 0x10 Stores the VISCA inquiry.
  • Page 52 〓〓〓〓〓〓 VISCA over IP 〓〓〓〓〓〓 equipment will save sequence number of each command, and return the sequence number to the controller. Payload According to Payload type, the following data will be saved. ⚫ VISCA command Save VISCA command packet ⚫ VISCA inquiry Save VISCA message packet ⚫...
  • Page 53 〓〓〓〓〓〓 VISCA over IP 〓〓〓〓〓〓 controller will wait for the return message then send the next command, we can detect and confirm if the peripheral equipment receive the commands from return message’s lag time. If controller shows it is overtime, it is regarded as error transmission.
  • Page 54 〓〓〓〓〓〓 VISCA over IP 〓〓〓〓〓〓 Sequence chart as following Sequence chart when returned message lost Sequence chart when command lost Note: Do not set IP address, sub net mask, gateway parameter in VISCA over IP command, otherwise, it will cause network breaks off. Due to change these parameter, network will be in off status.
