Notes on designing, programming,
12
validating and testing safety related
applications
12.3.8.2 Validation of FUP against AWL [IL] and parameters by means of validation
report
The programing carried out in the FUP must be compared with the AWL [IL] listing of the validation
report.
Example IL-Listing in validation report
Validation report
PLC program
Index Command
1 S1
2 S1
3 S1
4 S1
5 S1
6 S1
7 S1
8 S1
9 S1
10 S1
11 S1
12 SQH
13 LD
14 ST
15 SQC
16 SQH
17 LD
18 AND
19 ST
20 SQC
A step-by-step check is recommended. A more structured programming in the FUP makes the test more
efficient.
HB-37352-810-02-61F-EN SMX Gen2 Installation Manual
Operand
SLI_EN.1
SLI_EN.2
SLI_EN.3
SCA_EN.1
SCA_EN.2
SCA_EN.3
SLS_EN.2
SCA_EN.4
SLS_EN.3
SLS_EN.4
SLI_EN.5
E0.1
MX.2
E0.3
E0.4
MX.3
validated
Page 253/264
