Acromag XMC-ZU Series User Manual

Xilinx zynq ultrascale+ fpga based xmc modules
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XMC-ZU Series
Xilinx Zynq UltraScale+ FPGA Based XMC Modules
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: solutions@acromag.com
Copyright 2024, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501167A
