ACPS3320 CompactPCI-Serial AcroPack Carrier Board
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: solutions@acromag.com
Copyright 2019, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501141A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACPS3320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acromag ACPS3320

Summary of Contents for Acromag ACPS3320

  • Page 1 ACPS3320 CompactPCI-Serial AcroPack Carrier Board USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 295-0310 Email: solutions@acromag.com Copyright 2019, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8501141A...

  • Page 2: Table Of Contents

    Trademark, Trade Name and Copyright Information ................4 Radio Frequency Interference Statement ....................4 Environmental Protection Statement ..................... 4 ACPS3320 Overview ..........................4 KEY ACPS3320 FEATURES ........................5 Software Support............................. 5 Windows ............................5 VxWorks ............................6 Linux ..............................6 PREPARATION FOR USE ...........................
  • Page 3 EMC Compliance ..........................23 Vibration and Shock Standard ......................23 Reliability Prediction ........................23 CERTIFICATE OF VOLATILITY ........................24 ACPS3320-RTM Rear Transition Accessory Module ................25 7.1 Ordering Information ........................25 SIGNAL INTERFACE PRODUCTS ......................25 Cable ..............................25 Termination Panel ..........................26 7.2 Specifications ...........................

  • Page 4: General Information

    ACPS3320 Overview The ACPS3320 is a Compact Peripheral Component Interconnect – Serial (CPCI-S) card and is a carrier for mini-PCIe or AcroPack mezzanine modules. This carrier board provides a modular approach to system assembly, since each carrier can be populated with any combination of analog input/output, digital input/output, communication, etc.

  • Page 5: Key Acps3320 Features

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board replace several dedicated function PCI or PCIe bus boards. The ACPS3320 non- intelligent carrier board provides impressive functionality at low cost. Model Input/Output AcroPack Slots Operating Temperature Range ACPS3320 Rear I/O 2 (A, B) -40 to +85C...

  • Page 6: Vxworks

    Acromag AcroPack modules. Linux Acromag provides a software product consisting of Linux software. This software (Model APSW-API-LNX) is composed of Linux libraries for all AcroPack modules, VPX I/O board products, and PCIe I/O Cards. The software is implemented as a library of “C”...

  • Page 7: Preparation For Use

    It is important that the user employ satisfactory overall system design. It is understood and agreed by the Buyer and Acromag that this is the Buyer's responsibility. WARNING: This board utilizes static sensitive components and should only be handled at a static-safe workstation.

  • Page 8: Power And Cooling Considerations

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Figure 1 Connector and Fuse Locations Power and Cooling Considerations Refer to the specifications for loading and power requirements. Be sure that the system power supplies are able to accommodate the power requirements of the carrier board, plus the installed AcroPack modules within the voltage tolerances specified.

  • Page 9: Carrier Fuses

    CompactPCI-Serial Carrier Board Carrier Fuses CAUTION: Acromag has used pins labeled as reserved in the Mini-PCIe specification for additional power connections. If you are installing a Mini-PCIe card from another manufacturer in slot A remove fuses F1(+12V), F2(+5V) and F3 (-12V). When installing a Mini-PCIe card in from another manufacturer in slot B remove fuses F7(+12V), F8(+5V) and F9 (-12V).

  • Page 10: Field Grounding Considerations

    CONNECTORS The ACPS3320 carrier uses two AcroPack module field I/O connectors, two mini-PCIe connectors, and three CompactPCI-Serial backplane connectors. These are discussed in the following sections.
  • Page 11 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Carrier Module Pin Field I/O Signal P7, P8 Number Field I/O 9 Field I/O 10 Reserved/isolation Reserved/isolation Field I/O 11 Field I/O 12 Reserved/isolation Reserved/isolation Field I/O 13 Field I/O 14 Reserved/isolation Reserved/isolation Field I/O 15...
  • Page 12 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Carrier Module Pin Field I/O Signal P7, P8 Number Reserved/isolation Field I/O 27 Field I/O 28 Reserved/isolation Reserved/isolation Field I/O 29 Field I/O 30 Reserved/isolation Reserved/isolation Field I/O 31 Field I/O 32 Reserved/isolation Reserved/isolation...

  • Page 13: Mini-Pcie Connectors

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Carrier Module Pin Field I/O Signal P7, P8 Number Reserved/isolation Reserved/isolation Field I/O 45 Field I/O 46 Reserved/isolation Reserved/isolation Field I/O 47 Field I/O 48 Reserved/isolation Reserved/isolation Field I/O 49 Field I/O 50 Reserved/isolation...

  • Page 14: Compactpci-Serial Backplane Connections

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Table 2 Mini-PCIe Connectors J1 and J2 Pin Assignments Pin # Name Pin # Name +3.3V +12V -12V +1.5V Present N.C. (LED_WPAN#) N.C. (LED_WLAN#) +3.3V N.C. (LED_WWAN#) +3.3V USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V...
  • Page 15 1. Hash (#) is used to indicate an active-low signal. 2. BOLD ITALIC Logic Lines are NOT USED by the carrier board. The ACPS3320 field I/O connections are made through the CPCI-S rear backplane connectors P2 and P3. Tables 5 and 6 indicate the pin assignments for P2 and P3.
  • Page 16 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Table 5 CPCI-S P2 CONNECTIONS N.C. N.C. N.C. N.C. Site A Field I/O 49 Site A Field I/O 50 Site A Field I/O 41 Site A Field I/O 42 Site A Field I/O 33...
  • Page 17 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Table 6 CPCI-S P3 CONNECTIONS Site A Field I/O 2 Site A Field I/O 1 N.C. N.C. Site B Field I/O 41 Site B Field I/O 42 Site B Field I/O 33 Site B Field I/O 34...

  • Page 18: Jtag Programming/Debug Connector

    JTAG Programming/Debug Connector A JTAG programming/debug connector is provided for developing applications that use Acromag’s FPGA AcroPack modules. See reference designator P9 in Figure 1. This is a standard 14-pin Xilinx programming header for connecting a Xilinx Platform USB II programming device (or equivalent). The pin assignment for P9 is shown in 7.

  • Page 19: Theory Of Operation

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board TMS – JTAG Test Mode Select. This pin is the JTAG mode signal establishing appropriate TAP state transitions for target ISP devices sharing the same data stream. TCK – JTAG Test Clock. This pin is the clock signal for JTAG operations and should be connected to the TCK pin on all target ISP devices sharing the same data stream.

  • Page 20: Pcie Switch

    Important Note: The ACPS3320 board is not hot-swappable. DC/DC Converter The ACPS3320 has four DC/DC converters to provide the power supply voltages to the AcroPack modules that are not present on the CPCI-S backplane. The +3.3 Volt, +5 Volt and -12 Volt supplies are sourced from +12 Volt power.
  • Page 21 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board fuse locations are shown in Figure 1. The current rating for each of the fuses is listed in the Fuses paragraph in section 5. - 21 -...

  • Page 22: Service And Repair

    4. SERVICE AND REPAIR Surface-Mounted Technology (SMT) boards are generally difficult to repair. It is highly recommended that a non-functioning board be returned to Acromag for repair. The board can be damaged unless special SMT repair and service tools are used. Further, Acromag has automated test equipment that thoroughly checks the performance of each board.

  • Page 23: Specifications

    AcroPack modules. Power Board power requirements are a function of the installed AcroPack modules. This specification below lists current specified is for the ACPS3320 carrier board only. +12 Volts (8 %) 0.292A Typical Add the current for each of the AcroPack modules to calculate the total current required from each supply.

  • Page 24: Fuses

    Note: This is a Class A product Vibration and Shock Standard The ACPS3320 is designed to pass the following Vibration and Shock standards. Vibration, Sinusoidal Operating ..Designed to comply with IEC 60068-2-6: 10-500Hz, 5G, 2 Hours/axis Vibration, Random Operating ..Designed to comply with IEC 60068-2-64: 10-500Hz, 5G-rms, 2 Hours/axis Shock, Operating ......

  • Page 25: Certificate Of Volatility

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board 6. CERTIFICATE OF VOLATILITY Certificate of Volatility Acromag Model Manufacturer: ACPS3320 Acromag, Inc. 30765 Wixom Rd Wixom, MI 48393 Volatile Memory Does this product contain Volatile memory (i.e. Memory of whose contents are lost when power is removed) ■...

  • Page 26: Acps3320-Rtm Rear Transition Accessory Module

    7. ACPS3320-RTM Rear Transition Accessory Module The optional ACPS3320-RTM module may be installed into the slot directly behind the ACPS3320 to easily access AcroPack Field I/O on the ACPS3320’s P2 and P3 connectors. The I/O is routed to one 68 pin dual stack 0.8mm Champ connector mounted on the front panel of the ACPS3320-RTM.

  • Page 27: Termination Panel

    Model 5025-288 DIN-rail mountable panel provides 68 screw terminals for universal field I/O termination, SCSI-3 connector. 7.2 Specifications Physical Configuration Length (ACPS3320-RTM) ....3.150 inches (80.00 mm) Height ..........3.937 inches (100.00 mm) Board thickness ......0.063 inches (1.60 mm) Max component height ....0.402 inches (10.21 mm) Weight..........

  • Page 28: Rj3 Cpci-S Connector

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Site A Field I/O 19 Site A Field I/O 20 Site A Field I/O 11 Site A Field I/O 12 Site A Field I/O 3 Site A Field I/O 4 7.2.2 rJ3 CPCI-S Connector This connector is a 96-position Type G AirMax receptacle (10060905-101LF) specified by CPCI-S standard.

  • Page 29: J1 Field I/O Connector

    1. N.C. – not connected 7.2.3 J1 Field I/O Connector This connector is a 68-pin dual stack 0.8mm Champ cable connector which is mounted on the front panel of the ACPS3320-RTM. The pinout is as follows in the table below. J1 and AcroPack...
  • Page 30 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board J1 and AcroPack Termination Field I/O Signal Panel Reserved/isolation Field I/O 15 Field I/O 16 Reserved/isolation Reserved/isolation Field I/O 17 Field I/O 18 Reserved/isolation Reserved/isolation Field I/O 19 Field I/O 20 Reserved/isolation Reserved/isolation Field I/O 21...
  • Page 31 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board J1 and AcroPack Termination Field I/O Signal Panel Reserved/isolation Field I/O 33 Field I/O 34 Reserved/isolation Reserved/isolation Field I/O 35 Field I/O 36 Reserved/isolation Reserved/isolation Field I/O 37 Field I/O 38 Reserved/isolation Reserved/isolation Field I/O 39...

  • Page 32: Isolation

    Note: This is a Class A product Vibration and Shock Standard The ACPS3320-RTM is designed to pass the following Vibration and Shock standards. Vibration, Sinusoidal Operating ..Designed to comply with IEC 60068-2-6: 10-500Hz, 5G, 2 Hours/axis Vibration, Random Operating ..Designed to comply with IEC 60068-2-64: 10-500Hz, 5G-rms, 2 Hours/axis Shock, Operating ......
  • Page 33 AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board Temperature MTBF (Hours) MTBF (Years) Failure Rate (FIT 40°C 54,011,721 6,165.7 18.51 FIT is Failures in 10 hours. - 33 -...

  • Page 34: Certificate Of Volatility

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board 7.3 CERTIFICATE OF VOLATILITY Certificate of Volatility Acromag Model Manufacturer: ACPS3320-RTM Acromag, Inc. 30765 Wixom Rd Wixom, MI 48393 Volatile Memory Does this product contain Volatile memory (i.e. Memory of whose contents are lost when power is removed) ■...

  • Page 35: Revision History

    AcroPack Series ACPS3320 CompactPCI-Serial Carrier Board 8. REVISION HISTORY The following table shows the revision history for this document: Release Date Version EGR/DOC Description of Revision 26-JUL-2018 Preliminary release. 23-APR-2019 ENZ/ARP Release. - 35 -...
