APCe7012E-LF PCI Express AcroPack Carrier Board
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: solutions@acromag.com
Copyright 2019, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501138B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Acromag APCe7012E-LF
Summary of Contents for Acromag APCe7012E-LF
- Page 1 APCe7012E-LF PCI Express AcroPack Carrier Board USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 295-0310 Email: solutions@acromag.com Copyright 2019, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8501138B...
-
Page 2: Table Of Contents
Trademark, Trade Name and Copyright Information ................4 Radio Frequency Interference Statement ....................4 Environmental Protection Statement ..................... 4 APCe7012E-LF Overview.......................... 4 KEY APCe7012E-LF FEATURES ......................... 4 SIGNAL INTERFACE PRODUCTS ........................ 5 Cable ..............................5 Termination Panel ..........................5 Software Support............................. 5 Windows... - Page 3 Power ............................... 20 Fuses ..............................21 PCIe BUS COMPLIANCE .......................... 21 ENVIRONMENTAL ..........................21 EMC Compliance ..........................21 Vibration and Shock Standard ......................22 APCe7012E-LF Reliability Prediction ....................22 CERTIFICATE OF VOLATILITY ........................23 REVISION HISTORY ..........................23 - 3 -...
-
Page 4: General Information
-40 to +85°C (with 200 LFM airflow) KEY APCe7012E-LF FEATURES Interface for AcroPack modules – The APCe7012E-LF provides an electrical and mechanical interface for a mini-PCIe or AcroPack module. AcroPack modules are available from Acromag. Mini-PCIe cards are available from other... -
Page 5: Signal Interface Products
SIGNAL INTERFACE PRODUCTS This AcroPack carrier board will mate directly to all industry standard mini- PCIe and AcroPack modules. Acromag provides the following interface products (all connections to field signals are made through the carrier board which passes them to the individual AcroPack modules). -
Page 6: Linux
AcroPack Series APCe7012E-LF PCI Express Carrier Board Linux Acromag provides a software product consisting of Linux software. This software (Model APSW-API-LNX) is composed of Linux libraries for all AcroPack modules, VPX I/O board products, and PCIe I/O Cards. The software is implemented as a library of “C”... -
Page 7: Preparation For Use
It is important that the user employ satisfactory overall system design. It is understood and agreed by the Buyer and Acromag that this is the Buyer's responsibility. WARNING: This board utilizes static sensitive components and should only be handled at a static-safe workstation. -
Page 8: Board Configuration
AcroPack Series APCe7012E-LF PCI Express Carrier Board BOARD CONFIGURATION Power should be removed from the board when changing configurations, changing/removing fuses, or when installing AcroPack modules, cables and field wiring. Figure 1 Connector, Switch, and Fuse Locations Power and Cooling Considerations Refer to the specifications for loading and power requirements. -
Page 9: Carrier Fuses
PCI Express Carrier Board Carrier Fuses CAUTION: Acromag has used pins labeled as reserved in the Mini-PCIe specification for additional power connections. If you are installing a Mini-PCIe card from another manufacturer remove fuses F1, F2 and F3. Other fuse present on the board include +1.5V fuse F6. Also present on the board is +3.3V fuse F4. -
Page 10: Acropack Module Installation
AcroPack Series APCe7012E-LF PCI Express Carrier Board shown in Table below to assign a unique slot address to this carrier. Note: switch positions are indicated on the switch. Factory default address is zero. Table 2 Switch SW1 assignments SW1 Position... -
Page 11: Field Grounding Considerations
AcroPack input/output modules. CONNECTORS The APCe7012E-LF carrier uses an AcroPack module field I/O connector, a mini-PCIe connector, a field I/O Champ connector and one PCI Express bus interface connector. These are discussed in the following sections. - Page 12 AcroPack Series APCe7012E-LF PCI Express Carrier Board Carrier Carrier Module Pin Field I/O Signal J2 and Termination Number Panel Field I/O 7 Field I/O 8 Reserved/isolation Reserved/isolation Field I/O 9 Field I/O 10 Reserved/isolation Reserved/isolation Field I/O 11 Field I/O 12...
- Page 13 AcroPack Series APCe7012E-LF PCI Express Carrier Board Carrier Carrier Module Pin Field I/O Signal J2 and Termination Number Panel Reserved/isolation Field I/O 25 Field I/O 26 Reserved/isolation Reserved/isolation Field I/O 27 Field I/O 28 Reserved/isolation Reserved/isolation Field I/O 29 Field I/O 30...
-
Page 14: Mini-Pcie Connector
AcroPack Series APCe7012E-LF PCI Express Carrier Board Carrier Carrier Module Pin Field I/O Signal J2 and Termination Number Panel Reserved/isolation Reserved/isolation Field I/O 43 Field I/O 44 Reserved/isolation Reserved/isolation Field I/O 45 Field I/O 46 Reserved/isolation Reserved/isolation Field I/O 47... -
Page 15: Pci Express Bus Connections
AcroPack Series APCe7012E-LF PCI Express Carrier Board Table 4 Mini-PCIe Connector J1 Pin Assignments Pin # Name Pin # Name +3.3V +12V -12V +1.5V Present N.C. (LED_WPAN#) N.C. (LED_WLAN#) +3.3V N.C. (LED_WWAN#) +3.3V N.C. (USB_D+) N.C. (USB_D-) PETp0 PETn0 SMB_DATA SMB_CLK +1.5V... -
Page 16: Jtag Programming/Debug Connector
1. Asterisk (*) is used to indicate an active-low signal. 2. BOLD ITALIC Logic Lines are NOT USED by the carrier board. 3. +3.3Vaux power to AcroPack is not used by the carrier. Contact Acromag to enable +3.3Vaux power to the AcroPack module. The carrier provides +3.3V power to the module. -
Page 17: Programming Information
3.3 Volts. GND – Signal return. 3. PROGRAMMING INFORMATION This APCe7012E-LF carrier board has no end user programmable components. 4. THEORY OF OPERATION This section describes the functionality of the circuitry used on the carrier board. Refer to Figure 3 as you read this section. -
Page 18: Dc/Dc Converter
-12 Volt supply is sourced from +12 Volt host power. Slot Addressing The APCe7012E-LF carrier can be assigned a slot address by selecting the appropriate combination of switch settings. The slot address is 8 bits long and consists of 3 bits to identify the site on the carrier where the AcroPack module is installed (not used on this single slot AcroPack carrier) and 5 bits that are determined by the switch settings on the carrier. -
Page 19: Service And Repair
WHERE TO GET HELP If you continue to have problems, your next step should be to visit the Acromag worldwide web site at acromag.com. Our web site contains the most up-to-date product and software information. -
Page 20: Specifications
Isolated Power The use of an optional isolated DC/DC Converter is required for use with isolated Acromag AcroPack modules. See section 2 and Figure 1 for the carrier board location of the isolated DC/DC converter. Compatible DC/DC isolated converter modules are listed below:... -
Page 21: Fuses
-40 to +85°C (with 200 LFM airflow) Relative Humidity 5-95% non-condensing Storage Temperature -55 to +125°C. EMC Compliance The APCe7012E-LF is designed to comply with EMC Directive 2004/108/EC. Immunity per EN 61000-6-2 Electrostatic Discharge Immunity (ESD), per IEC 61000-4-2 Radiated Field Immunity (RFI), per IEC 61000-4-3... -
Page 22: Vibration And Shock Standard
AcroPack Series APCe7012E-LF PCI Express Carrier Board Vibration and Shock Standard The carrier is designed to pass the following Vibration and Shock standards. Vibration, Sinusoidal Operating Designed to comply with IEC 60068-2-6: 10- 500Hz, 5G, 2 Hours/axis Vibration, Random Operating... -
Page 23: Certificate Of Volatility
AcroPack Series APCe7012E-LF PCI Express Carrier Board 7. CERTIFICATE OF VOLATILITY Certificate of Volatility Acromag Model Manufacturer: APCe7012E-LF Acromag, Inc. 30765 Wixom Rd Wixom, MI 48393 Volatile Memory Does this product contain Volatile memory (i.e. Memory of whose contents are lost when power is removed) ■...
