- Page 1 35-3001-11-XX Combustible Gas/Carbon Dioxide Sample-Draw Detector Operator’s Manual Part Number: 71-0539 Revision: P1 Released: 10/20/20 www.rkiinstruments.com...
- Page 2 WARNING Read and understand this instruction manual before operating detector. Improper use of the detector could result in bodily harm or death. Periodic calibration and maintenance of the detector is essential for proper operation and correct readings. Please calibrate and maintain this detector regularly! Frequency of calibration depends upon the type of use you have and the sensor types.
- Page 3 Product Warranty RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials, workmanship, and performance for a period of one year from date of shipment from RKI Instruments, Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of charge.
-
Page 4: Table Of Contents
Table of Contents Overview ..............5 Specifications . -
Page 5: Overview
Exhaust Exhaust Line Length for 50 feet 0 feet 1/4” O.D. x 1/8” I.D. Tubing * RKI Instruments, Inc. does not recommend installing this tubing size on both the inlet and exhaust. Maximum Recommended Inlet/ Inlet Exhaust Exhaust Line Length for... - Page 6 Table 1: Specifications Accuracy Combustible Gas: ± 5% of reading or ± 2% LEL (whichever is greater) Carbon Dioxide: ± 5% of reading or ± 2% of full scale (whichever is greater) WARNING: When using the 35-3001-11-XX, you must follow the instructions and warnings in this manual to assure proper and safe operation of the 35-3001-11-XX and to minimize the risk of personal injury.
-
Page 7: Description
Description This section describes the components of the sample-draw detector. Pump Connector Oxy gen Sensor Mounting Flowmeter Circuit Terminal Foot, 4X Board Connector Strip Sensor Flow Control V alve Pump Fail LED IR CO 2 Sensor Pilot LED (inside b lock) IR CO 2 Flow Block IR CO 2... -
Page 8: External Components
External Components This section describes the sample-draw detector’s external components. Housing The sample-draw detector’s fiberglass housing is weather- and corrosion-resistant. It is suitable for installation where general purpose equipment is in use. The housing door is hinged on the left side and is secured by two latches on the right side. The flowmeter and status LEDs are visible through a window in the housing door. - Page 9 Main Circuit Board The main circuit board includes the detector/amp terminal strip, interconnect terminal strip, oxygen sensor terminal strip, pump connector, and flowmeter circuit board connector (see Figure 1). Detector/Amp Terminal Strip The detector/amp terminal strip is the upper twelve-point terminal strip in the bottom right corner of the main circuit board.
- Page 10 Sensor Flow Control Valve The sensor flow control valve is mounted to the flowmeter circuit board above the flowmeter. The sensor flow control valve adjusts the flow rate to the detector. Turn the valve’s knob clockwise to increase the flow and counterclockwise to decrease the flow. Status LEDs Two status LEDs are above the flowmeter.
-
Page 11: Installation
sensor and retains it in the flow block. The cable is wired to the main PCB. The IR carbon dioxide sensor PCB allows you to replace the sensor without disconnecting the wiring. Installation This section describes procedures to mount the sample-draw detector in the monitoring environment and wire the sample-draw detector to a controller. -
Page 12: Connecting The Sample Lines To The Sample-Draw Detector
2. Push 1/4” O.D. rigid polypropylene or rigid Teflon sample tubing into the fitting until it stops. Flexible polyurethane tubing may be used with an appropriate insert. RKI Instruments, Inc. recommends using either 1/4” O.D. x 1/8” I.D. or 1/4” O.D. x 0.170” I.D. tubing based on your length requirements. -
Page 13: Wiring The Sample-Draw Detector To A Controller
2. Push 1/4” O.D. rigid polypropylene or rigid Teflon sample tubing into the fitting until it stops. Flexible polyurethane tubing may be used with an appropriate insert. RKI Instruments, Inc. recommends using either 1/4” O.D. x 1/8” I.D. or 1/4” O.D. x 0.170” I.D. tubing based on your length requirements. - Page 14 CAUTION: If using shielded cable, leave the cable shield’s drain wire insulated and disconnected at the sample-draw detector. You will connect the opposite end of the drain wire at the controller. 7. Route the cable or wires in conduit leading from the sample-draw detector through one of the conduit hubs at the controller.
-
Page 15: Start Up
Start Up This section describes procedures to start up the sample-draw detector and place the sample-draw detector into normal operation. Introducing Incoming Power 1. Complete the installation procedures described earlier in this manual. 2. Verify that the wiring is correct and secure. Refer to the controller operator’s manual for connections at the controller. -
Page 16: Maintenance
4. Verify a reading of 0% LEL for the combustible gas channel and 0 ppm or 0% vol for the CO channel at the controller display screen. If the display reading is 0% LEL and 0 ppm or 0% vol, start up is complete. The sample-draw detector is in normal operation. -
Page 17: Troubleshooting
5. If the fail condition continues, replace the sensor(s) as described in “Replacing Components of the Sample-Draw Detector” on page 18. 6. If the fail condition continues, contact RKI Instruments, Inc. for further instruction. Slow or No Response/Difficult or Unable to Calibrate Symptoms •... -
Page 18: Replacing Components Of The Sample-Draw Detector
4. If you cannot set the correct flow rate, check the sample line for obstructions or kinks. 5. If the calibration/response difficulties continue, replace the sensor as described later in this section. 6. If the calibration/response difficulties continue, contact RKI Instruments, Inc. for further instruction. - Page 19 9. Close and latch the housing door. 10. Turn on power to the controller. 11. Turn on the controller. CAUTION: Allow the replacement sensor to warm up for 5 minutes before you continue. 12. Calibrate the replacement sensor as described in “Calibration” on page 22. Replacing the Hydrophobic Filter 1.
-
Page 20: Adjusting The Low Flow Setting
Adjusting the Low Flow Setting NOTE: Adjusting the low flow setting will cause a low flow alarm at the sample-draw detector and a fail alarm at the controller. Be sure to put the controller into its calibration program or disable external alarms before performing this test. -
Page 21: Removing The Particle Filter's Tubing Stub, If Necessary
Removing the Particle Filter’s Tubing Stub, if Necessary A short tubing stub comes factory installed in the particle filter. It is used for connecting the particle filter to the inlet fitting. If you have installed the particle filter and no longer want it installed, you will need to remove the particle filter’s tubing stub from the inlet fitting and replace it with tubing. -
Page 22: Calibration Frequency
3 months is adequate for most sample draw detector applications. Unless experience in a particular application dictates otherwise, RKI Instruments, Inc. recommends a calibration frequency of every 3 months for the combustible gas sensor and every 6 months for the infrared CO sensor. -
Page 23: Setting The Response Reading
Setting the Response Reading 1. Screw the regulator into the combustible gas calibration cylinder. 2. Connect the sample tubing from the demand flow regulator to the sample-draw detector’s inlet line. 3. Allow the sample-draw detector to draw sample for one minute. 4. -
Page 24: Parts List
Parts List Table 2 lists replacement parts and accessories for the sample-draw detector. Table 2: Parts List Part Number Description 06-1248RK Sample tubing, 3/16” ID x 5/16” OD, specify length 06-1248RK-03 Sample tubing, 3/16” ID x 5/16” OD, 3 feet (for calibration kit) 07-0110RK Gasket for IR flow block 17-2670... - Page 25 Table 2: Parts List Part Number Description 81-0076RK-01 Zero air calibration cylinder, 34 liter steel 81-0076RK-03 Zero air calibration cylinder, 103 liter 81-0078RK-01 Calibration cylinder, 100% nitrogen, 34 liter steel 81-0078RK-03 Calibration cylinder, 100% nitrogen, 103 liter 81-1054RK Regulator, demand flow, for 34 liter aluminum, 58 liter, and 103 liter cali- bration cylinders (cylinders with internal threads) 81-1055RK Regulator, demand flow, for 17 liter and 34 liter steel calibration cylinders...
