Hardware Supplied - Mocka Jesse Assembly Instructions Manual

Jesse
Six Drawer
A
B
dowel
screw
x30
x42
J
K
long cam cam nut
screw bolt
x8 x4
V
safety
strap x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
mocka.co.nz I mocka.com.au
C D
bolt locking
x50 nut x50
L M
wedge
x4 x4

HARDWARE SUPPLIED

W
screw
x 4
WALL STRAP
E CL
small slide
screw rail x6
x72
N O
screw plastic
x4 glide
x5
X
wall
anchor x 2 screw x 2
Phillips & Flathead screwdrivers
and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
