R
Assembly Instructions
Gustav 48" Cane Door Bookcase
SKU - 618184
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST WORLD MARKET STORE
IF YOU ARE NOT NEAR A STORE PLEASE CALL OUR CUSTOMER SERVICE CALL
CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE.
All products sold at World Market are not for commercial use and are intended for residential use only.
Page 1
2022.07.20
Advertisement
Table of Contents
Related Manuals for World Market Gustav 618184
Summary of Contents for World Market Gustav 618184
- Page 1 IF YOU ARE NOT NEAR A STORE PLEASE CALL OUR CUSTOMER SERVICE CALL CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE. All products sold at World Market are not for commercial use and are intended for residential use only. Page 1...
-
Page 2: Component List
Component List Q.TY LABEL PICTURE DESCRIPTION Top Frame Bottom Frame Shelf Left Side Frame Right Side Frame Back Panel Vertical Rail Left Door Right Door Page 2... -
Page 3: Hardware List
Hardware List Q.TY LABEL PICTURE DESCRIPTION Cam lock Ø15 mm Cam Screw Connecting Screw M7 x 50 mm Wood Screw M4 x 30 mm Shelf Pin Ø6 Pan Head Screw M3.5 x 15 mm Anti Tip-kit Tool List LABEL PICTURE DESCRIPTION Allen Key 4 x 110 x 30 mm Phillips Screwdriver... -
Page 4: Assembly Preparation
Do not assemble on flooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until finished. In case of missing parts, please contact your nearest World Market store or call our customer service call center at call 1-877-967-5362. Page 4... -
Page 5: Assembly Steps
Assembly Steps Step 1 (H-2) Cam Screw x 4 (T-2) Phillips Screwdriver Make sure Cam Screws are tightened fully as shown Place Top Frame (A) upside down onto a padded, non-marring surface. Install Cam Screws (H-2) into the pre-drilled holes on Top Frame (A) as shown. Fully tighten using a Phillips screwdriver (T-2, not included) per illustration above. - Page 6 Step 2 (H-1) Cam Lock x 4 (T-1) Allen key Front Attach Top Frame (A) to Left/ Right Side Frame (E-1/E-2) by inserting previously installed Cam Screws (H-2) into receiving holes. Install Cam Locks (H-1) into the corresponding holes inside upper sides of Left/ Right Side Frame (E-1/ E-2) as illustrated.
- Page 7 Step 4 (H-4) Wood Screw x 2 (T-2) Phillips Screwdriver Front Secure the Vertical Rail (G) using Wood Screws (H-4) and a Phillips Screwdriver (T-2) (not included). Step 5 (T-1) Allen key (H-3) Connecting Screw x 6 Front Secure Bottom Frame (B) to Left Side Frame (E-1) and Right Side Frame (E-2) using Connecting Screws (H-3). Engage all screws before fully tightening using Allen Key (T-1).
- Page 8 Step 6 Front Position and secure Legs (D) to each metal threaded plate at the corners of Bottom Frame (B) as shown. Secure each leg by threading the stud clockwise until it is snug against the metal plate. DO NOT OVER TIGHTEN LEGS. Step 7 (H-6) Pan Head Screw x 40 (T-2) Phillips Screwdriver...
- Page 9 Step 8 (H-5) Shelf Pin x 10 Front Using a second person to assist you, turn assembly upright onto Legs (D). Insert Shelf Pins (H-5) into the desired hole locations on Left Side Frame (E-1), Right Side Frames (E-2) and Vertical Rail (G). Turn Shelves (C) diagonally and carefully insert into position as shown, making sure they rest evenly on each Shelf Pin (H-5).
- Page 10 Step 9 Step 9.2b Step 9.2a Front Step 9.1 NOTE: There are adjustment screws on the lower wheels as illustrated above. Turn the set screw clockwise to adjust the wheels INWARD which will decrease the gap between the bottom track and the bottom of the door. Adjust the set screw counter-clockwise to adjust the wheels OUTWARD which will increase the gap between the bottom track and the bottom of the door.
- Page 11 Step 10 ADJUSTABLE LEVELER NOTE: Levelers can be used for adjustment if needed. Ensure that all bolts have been fully tightened. Assembly is now complete and the Gustav 48" Cane Door Bookcase is ready for use. NOTE: Levelers can be adjusted for additional stability if needed. Page 11...
-
Page 12: Care And Maintenance
Do not write on furniture without a padded barrier to protect the surface. Do not place furniture outside. For indoor use only. All products sold at World Market are not for commercial use and are intended for residential use only. - Page 13 Anti-Tip Measures Warning - Children may be injured by tipping of furniture and the use of the Anti-Tip Kit is highly recommended. This Anti-Tip Kit is only a deterrent It is not a substitute for proper adult supervision. Manufacturer and retailer assumes no liability for improper installation or excess loads placed on screws, brackets, or straps.
- Page 14 Customer Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or partial credit, in the sole discretion of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
