User Manual
®
Hotwire
8303/8304 IDSL Cards
Installation Instructions
Document Number 8303-A2-GZ40-10
August 2000
What is a Hotwire 8303/8304 IDSL Card?
A Hotwire
(IDSL) card is a circuit card assembly that contains 24 ports, an interface to the
Network Service Provider (NSP), and a processor.
When the 8303/8304 IDSL card is used in a Hotwire 8610/8810 Digital Subscriber
Line Access Multiplexer (DSLAM) or 8820 GranDSLAM chassis and connected to
a Hotwire 6301/6302 DSL Router, it provides high-speed Internet or intranet
access over traditional twisted-pair telephone wiring.
Product Documentation Online
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following documents:
To order a paper copy of a Paradyne document:
T
T
8303-A2-GZ40-10
®
8303/8304 Integrated Services Digital Network Digital Subscriber Line
IDSL Card
Chassis Type
8303
8610/8810 DSLAM or
8820 GranDSLAM
8304
8820 GranDSLAM
Technical Manuals
8000-A2-GB22
Hotwire Management Communications Controller (MCC) Card, IP
Conservative, User's Guide
8000-A2-GB26
Hotwire IP MVL, RADSL, IDSL, and SDSL Cards, Models 8310/8312/8314,
8510/8373/8374, 8303/8304, and 8343/8344, User's Guide
8021-A2-GB20
Hotwire Shelf Concentration Module (SCM) Card User's Guide
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
Outside the U.S.A., call 1-727-530-8623
August 2000
Uplink
Interface Type
Endpoint Used
Ethernet
6301 or 6302 IDSL
Router
ATM via SAR
childcard
Hotwire DSL & MVL Systems .
1
Advertisement
Related Manuals for Paradyne Hotwire 8303
Summary of Contents for Paradyne Hotwire 8303
-
Page 1: Product Documentation Online
IDSL Card 8303 8304 When the 8303/8304 IDSL card is used in a Hotwire 8610/8810 Digital Subscriber Line Access Multiplexer (DSLAM) or 8820 GranDSLAM chassis and connected to a Hotwire 6301/6302 DSL Router, it provides high-speed Internet or intranet access over traditional twisted-pair telephone wiring. - Page 2 Refer to one of the above installation documents to: — Install and set up the Hotwire DSLAM or GranDSLAM — Install the Hotwire 8303/8304 IDSL Card — Connect cables After the IDSL card is installed, there are configuration procedures that must be performed before you can begin to use the IDSL cards for Internet or intranet connectivity.
- Page 3 1. If there is a filler plate covering the slot, remove it. 2. Insert the card into the card guides of the slot on the chassis. For the 8303 IDSL card in an 8610 DSLAM, ensure that the components are facing up.
- Page 4 8303 IDSL card failure. System processing functions have stopped. No power to card. Alrm Yellow, On Alarm is present on the Hotwire 8303 IDSL card. Ethernet (ETH1) interface is not being detected. Normal operation, no alarms. Test Yellow, On Test in progress.
- Page 5 DSL PORT ALT BANK 13-24 1-12 IDSL 8304 00-16781 8303-A2-GZ40-10 LED is . . . Indicating . . . Green, Card functioning normally. Winking describes a Winking recurring pulse when the LED is ON longer than OFF at a ratio of approximately 10:1.
-
Page 6: Warranty, Sales, Service, And Training Information
Hotwire is a registered trademark of Paradyne Corporation. MVL is a trademark of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners. Copyright © 2000 Paradyne Corporation. Printed in U.S.A. . *8303-A2-GZ40-10* August 2000 8303-A2-GZ40-10...
