Loop Detector
LD-1123-PAQ
Installation Manual
The LD-1123-PAQ Loop Detector is designed to be used with gates or other vehicle detection
systems. The LD-1123-PAQ is connected to an input loop which is buried in the pavement. If a
vehicle is over the input loop, the detector sends a signal to perform such actions as opening a
gate, holding a gate open, or indicating that a vehicle is in a bay.
 Single loop input
 3 Adjustable sensitivity settings
 2 Form "C" relay outputs
 11-pin connector
 ABS plastic housing
 Power-on automatic reset
 Automatic drift compensation for varying environmental conditions
 Auto fault detection
 Terminal block included
