TABLE OF CONTENTS:
1.00
BEAMS & CONNECTORS:
1.10
1.20
1.30
2.00
2.10
2.20
3.00
3.10
3.20
3.30
3.31
3.40
3.41
3.42
3.43
Revision History:
Date
email:
info@matsing.com
MS-8C60
Date
Prepared by
22 Jul 2022
Ray Ling
INSTRUCTION MANUAL MS-8C60
Description
website:
Instruction Manual
Approved by
Pavel
www.matsing.com
Document nos
MS-8C60-IM-001
Revision
Revised by
nos.
Page
Revision
00
1
/
6
Advertisement
Table of Contents
Related Manuals for Matsing MS-8C60
Summary of Contents for Matsing MS-8C60
- Page 1 Date Prepared by Approved by Document nos Revision 22 Jul 2022 Ray Ling Pavel MS-8C60-IM-001 INSTRUCTION MANUAL MS-8C60 TABLE OF CONTENTS: 1.00 BEAMS & CONNECTORS: 1.10 Plan View Resultant Beam Direction 1.20 Plan View Connector Layout 1.30 Connector Ports Table 2.00...
- Page 2 1.00 BEAMS & CONNECTORS: 1.10 Plan View Resultant Beam Direction 0˚ Plan View Resultant Beam Directions Frequency: 3700 – 4200 MHz 1.20 Plan View Connector Layout MS-8C60 PLAN VIEW CONNECTOR LAYOUT Page...
- Page 3 1.30 Connector Ports Table BEAM BEAM BEAM BEAM BEAM BEAM BEAM BEAM 2.00 PATTERN DIAGRAM 2.10 Vertical Beam Pattern Vertical Beam Pattern Rear Front Frequency: Bottom 3700 - 4200 MHz 2.20 Horizontal Beam Pattern Frequency: 3700 - 4200 MHz Horizontal Beam Pattern Page...
- Page 4 3.00 TRANSPORTATION / INSTALLATION 3.10 Transportation (From Point to Point) Strictly comply to the Local authority and regulatory on Workplace Safety and Health Control and Measure when moving and transportation of large or heavy equipment, appropriate material handling machine should be use. (Risk Assessment apply for Forklift or Pallet Truck Lifting) 3.20 Bracket Mounting...
- Page 5 3.30 Installation using a crane Strictly comply to the local authority and regulatory on Workplace Safety and Health Control and Measure when performing lifting of large or heavy equipment, appropriate material handling machine should be used and only certified personnel should perform the task. (Risk Assessment requirement applies for both Up-Lifting and Down-Lifting.) 3.31 Lifting the Antenna...
- Page 6 3.40 Antenna Installation With reference to Item Bracket Mounting Procedure, End user is required to Custom-Make the additional supporting bracket and tighten it to the existing Antenna bracket to meet the deployment needs. 3.41 Antenna Leveling After the Antenna is mounted to the bracket, it is required to be adjusted to 0˚ (Zero Degree) with ≤0.2˚...
