TABLE OF CONTENTS:
1.00
BEAMS & CONNECTORS:
1.10
Plan View Resultant Beam Layout
1.20
Connector Ports Table
1.30
Connector Detail
1.40
Connector Layout
2.00
PATTERN DIAGRAM
2.10
Frequency: 1710 - 2690 MHz
2.11
Horizontal Pattern
2.12
Vertical Pattern
3.00
RET Operations / Information
3.10
Display & Information Reference
3.20
Model & S/N Reference From Label
Beam Nos & Port Nos Display
3.30
4.00
MANUAL TILT ADJUSTMENT
5.00
BRACKET INSTALLATION
5.10
Bolts & Nuts Requirements
5.11
Bolts & Nuts
5.12
Bracket
5.20
Tools Requirement
5.21
Adjustable Spanner
5.22
M12 Spanner
5.30
Bracket Spacing & Installation Sample
Revision History:
Date
07-Apr-21
To include the bracket installation process.
21-Jan-22
Add RET Handle Caution sticker
To Include RET Operations/Information & Add in RET Serial
23-Feb-24
nos. Sticker on the Antenna Backshell
email:
info@matsing.com
MS-MBA-3-H2
Date
Prepared by
Ray Ling
INSTRUCTION MANUAL MS-MBA-3-H2
Description
website:
Approved by
Pavel
www.matsing.com
Instruction Manual
Document nos
MS-MBA-3-H2-IM-001
Revision
Revised by
nos.
Ray Ling
Ray Ling
Ray Ling
Page
Rev
3
1
2
3
1
/
6
Advertisement
Related Manuals for Matsing MS-MBA-3-H2
Summary of Contents for Matsing MS-MBA-3-H2
- Page 1 MS-MBA-3-H2 Instruction Manual Date Prepared by Approved by Document nos 23 Feb 2024 Ray Ling Pavel MS-MBA-3-H2-IM-001 INSTRUCTION MANUAL MS-MBA-3-H2 TABLE OF CONTENTS: 1.00 BEAMS & CONNECTORS: 1.10 Plan View Resultant Beam Layout 1.20 Connector Ports Table 1.30 Connector Detail 1.40...
- Page 2 Plan View Resultant Beam Directions Frequency: 1710 – 0 MHz 1.30 Connector Detail BEAM 2 1.40 Connector Layout MS-MBA-3-H2 REAR VIEW CONNECTOR LAYOUT BEAM 3 BEAM 2 BEAM 1 AISG IN HB Beams: 1,2,3 HB Ports: 1 to 6 Page...
- Page 3 2.00 PATTERN DIAGRAM 2.10 Frequency: 1710 - 2690 MHz 2.11 Horizontal Pattern Frequency: MS-MBA-3-H2 1710 - 2690 MHz 2.12 Vertical Pattern MS-MBA-3-H2 Frequency: 1710 - 2690 MHz Page...
- Page 4 3.00 RET Operations / Information A standard AISG 2.0 compliant cable (not included) is used to connect the MDCU to the AISG interface control. Once connected, use an AISG 2.0 compliant Control software to perform a Sub Unit SCAN to identify the RET Elements. 3.10 Display &...
- Page 5 4.00 MANUAL TILT ADJUSTMENT The MBA antenna come in RET mode as default, but if needed can also be manually adjusted. To do so, please unscrew the waterproof cap behind the element whose tilt is to be adjusted. By Default the knob is on engaged mode, pull out the handle for manual tilt adjustment, turn the handle to change the tilt.
- Page 6 5.00 BRACKET INSTALLATION 5.11 Bolts & Nuts 5.10 Bolts & Nuts Requirements Bracket Bolts Nuts Size Size M12 x 200mm ***Additional Lock Nuts M12 x 4pcs 5.12 Bracket 5.20 Tools Requirement 5.21 Adjustable Spanner 5.22 M12 Spanner 5.30 Bracket Spacing & Installation Sample Page...
