- Page 1 LOFT / LOUNGE PING PONG INSTALLATION MANUAL REV 2003-04- CANADA BILLIARD & BOWLING INC. 4050 Industriel blvd, Laval, QC, H7L 6C3 450-963-5060 W W W.CANADABIL LIARD.COM...
-
Page 2: Lifetime Guarantee
LIFETIME GUARANTEE CANADA BILLIARD is pleased to offer an unsurpassed LIFETIME GUARANTEE TO THE ORIGINAL PURCHASER against defects in material and workmanship, provided installation and/or service is performed by an Authorized Dealer or a factory-approved installer. Cloth, pockets and rail cushions are not covered under this guarantee. - Page 4 1 According to the picture above, place the hardware 2 Prepare the leg levelers if they are not already on a clean surface. installed to the legs. Install each four levelers in position. Install 8mm dowel pins to the long base frame. 5 Using the dowel pins for alignement, install the tiner 6 Fix these 2 crossmembers with 3/8"-16 x 1 1/4"...
- Page 5 8 Fix the net crossmember with 3/8"-16 x 1 3/4" 7 Using the dowel pins for alignement, install the net hexagonal bolts and 13/32" plat wachers. crossmembers (thicker crossmember). 9 Fix both long aprons to the crossmembers using 10 Fix the first short apron's corners to the long 1/4"- aprons 20 x 1 1/2"...
- Page 6 13 Slide both chrome poles in place into the net 13 Install the legs with 3 8"-16 x 1" hexagonal bolts and 7/16".flat wachers.. WITH HELP, TURN OVER THE crossmember underneath the metal plate. ASSEMBLED TABLE AND PUT IT IN PLACE. 14 Loosely screw the 3/8"-16 x 1 1/2"...
- Page 7 20 Insert the angular end of the rod into the holes on the 21 Insert the upper part of the rod into the upper part of bottom of the chrome poles. the chrome pole, 22 Thighten the net by pulling the chorme pole from the 23 Tighten the chrome pole with the winged nut pingpong table..
- Page 8 YOU ARE NOW READY TO PLAY YOUR FIRST GAME OF PINGPONG ON YOUR MAGNIFICENT PING PONG TABLE FROM CANADA BILLIARD ! CONGRATULATIONS ! CANADA BILLIARD & BOWLING INC. 4050 Industriel blvd, Laval, QC, H7L 6C3 450-963-5060 W W W.CANADABILLIARD.COM...
