Furniture of America CM-FC612 Assembly Instructions Manual

Download this manual

Assembly Instructions

CM-FC612

ASSEMBLY RATING

Tools Required for Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Allen Wrench

(Included)

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

DIFFICULT

EASY

Page 1 of 6

Rev.14-12-16

Need help?

Do you have a question about the CM-FC612 and is the answer not in the manual?

Page 1 Assembly Instructions CM-FC612 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Page 2 of 6...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Parts List (Continued) #1 x 1 pc #8 x 5 pcs Backrest Caster #2 x 1 pc Seat Hardware List #3R x 1 pc...
Page 4 Insert the 5 casters (#8) into the 5-star base (#4). Then insert the gas lift cylinder (#7) into the 5-star base (#4) and the cylinder cover (#6) over the gas lift cylinder (#7). Turn right (clockwise) to tighten #B x 4 pcs #C x 4 pcs Align the seat plate with handle (#5) with the pre-drilled holes...
Page 5 Align the right armrest (#3R) and the left armrest (#3L) with the pre-drilled holes on the sides of the seat (#2). Insert 4 bolts (#A) through the pre-drilled holes on the armrests and secure those bolts using the Allen wrench (#E) to lock them with the seat (#2).
Page 6 Place the assembled seat plate with handle (#5) onto the assembled gas lift cylinder (#7). Make sure the parts are firmly secured. With the chair rested on a flat surface, check that all parts are secured, the chair is stable and the up/down lift is working properly. ASSEMBLY IS COMPLETED Page 6 of 6...
