VERSION # 21-07-15
1 / 12
MODEL #
CM-DK825
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM-DK825
Summary of Contents for Furniture of America CM-DK825
- Page 1 MODEL # CM-DK825 Questions? GIVE US A CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 12...
- Page 5 CORNER DESK CM-DK825 2pcs Large Table Top Small Table Top Shelf Panel Left Side Frame 2pcs Right Side Frame Support Bar Side Frame Cross Bar 2pcs 2pcs Large Tension Bar Small Tension Bar 24pcs 8pcs 2pcs 3pcs Bolts Ø1/4" x 1/2"...
- Page 6 5pcs 6pcs Hex Nut Flat Washers Ø5/8" Allen Wrench 4mm Wrench 14mm 2pcs USB Port Screws Ø3.5 x 15mm 6 / 12...
- Page 7 ASSEMBLY INSTRUCTIONS Part #9 x2pcs Hardware #A x1pc Hardware #E x1pc Align tension bars (#9) to each other, then secure by using bolt (#A) with nut (#E). Part x2pcs Hardware #A x1pc Hardware #E x1pc Align tension bars (#10) to each other, then secure by using bolt (#A) with nut (#E).
- Page 8 ASSEMBLY INSTRUCTIONS Align cross bar (#7) to the side frames (#4,5), then secure by using bolts (#C). Part #4 x1pc Part #5 x1pc Part #7 x1pc Hardware #C x2pcs Align frames to the table top (#1), Part #1 x1pc then secure by using bolts (#A). Hardware #A x6pcs 8 / 12...
- Page 9 ASSEMBLY INSTRUCTIONS Align tension bars (#9) to the side frames (#4,5), then secure by using bolts (#A). Part #9 x2pcs Hardware #A x4pcs Part #3 x2pcs Part #6 x2pcs Align shelf panels (#3) to the side Hardware #B x8pcs frames (#6), then secure by using bolts (#B).
- Page 10 ASSEMBLY INSTRUCTIONS Align support bar (#8) to the frames (#5,6), then secure by using bolts (#A). Part #8 x1pc Hardware #A x2pcs Part #10 x2pcs Hardware #A x4pcs Align tension bars (#10) to the side frames, then secure by using bolts (#A). 10 / 12...
- Page 11 ASSEMBLY INSTRUCTIONS Align table top (#2) to the frame, then secure by using bolts (#A). Part #2 x1pc Hardware #A x6pcs Hardware #D x3pcs Secure both table tops (#1,2) by Hardware #E x3pcs using bolts (#D) with washers (#F) Hardware #F x6pcs onto nuts (#E) with washers (#F).
- Page 12 ASSEMBLY INSTRUCTIONS Hardware #I x1pc Hardware #J x2pcs 12 / 12...
