CM-FC603
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 7
Rev.14-07-16
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-FC603
Summary of Contents for Furniture of America CM-FC603
- Page 1 Assembly Instructions CM-FC603 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 7...
- Page 4 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Parts List (Continued) #1 x 1 pc #9 x 1 pc 5-Star Base Headrest #2 x 5 pcs Caster Hardware List...
- Page 5 Insert the 5 casters (#2) into the 5-star base (#1). Then insert the gas lift cylinder (#3) into the 5-star base and the cylinder cover (#4) over the gas lift cylinder (#3). Align the seat plate with handle Turn right (clockwise) to tighten (#5) with the pre-drilled holes on the bottom of the seat (#7).
- Page 6 #B x 4 pcs Align the backrest (#6) with the pre-drilled holes on the bottom of the seat (#7). Insert 4 screws (#B) through the bottom of the backrest (#6) using the Allen wrench (#F) to lock them with the seat (#7). Turn right (clockwise) to tighten #E x 1 pc Align the headrest (#9) with...
- Page 7 Carefully place the assembled seat plate with handle (#5) onto the assembled gas lift cylinder (#3). Make sure the parts are firmly secured. Make sure the chair is rested on a flat surface. Check that all parts are secured, the chair is stable and the up/down lift is working properly.
