- Page 1 CR2 JR. COMPLETE RESTROOM RESTORATION 12 GALLON PROFESSIONAL RESTROOM CLEANER OWNER’S/OPERATOR’S MANUAL PROUDLY DESIGNED AND MANUFACTURED BY WWW.EDIC-USA.COM Revised 2-20-2024...
-
Page 2: Table Of Contents
TABLE OF CONTENTS RECEIVING YOUR EQUIPMENT................... WARNINGS AND SAFETY....................3, 4 ELECTRICAL INFORMATION..................GFCI INFORMATION....................... GROUNDING INSTRUCTIONS..................MAINTENANCE........................ CORD STORAGE AND SAFETY..................MACHINE LAYOUT-REAR....................INCLUDED ACCESSORIES....................INSTALLING METERING TIPS..................ASSEMBLING THE ACCESSORY RACKS..............OPENING THE MACHINE..................... OPERATING THE 9000AC-1 SPRAY GUN..............OPERATING INSTRUCTIONS FOR HARD SURFACE CLEANING....... -
Page 3: Receiving Your Equipment
FAILURE TO COMPLY WITH THE FOLLOW- When your package is delivered, check the carton care- ING WARNINGS AND INSTRUCTIONS WILL fully for signs of rough handling. If your CR2 JR is VOID THE WARRANTY. damaged, notify the carrier immediately and request an inspection. -
Page 4: Electrical Information
Prevent burns by wearing gloves or using a barrier to operating conditions. When the electrical system has remove hot quick disconnects. been disabled, you will not be able to run the CR2 JR, at • This is not a toy. Keep away from children. -
Page 5: Grounding Instructions
Figure 1. Replace the power cord if the grounding pin is damaged or broken. Press the “RESET” button on the GFCI and the CR2 JR will be fully functional again. Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong plugs and outlets. -
Page 6: Maintenance
Do not pull or carry by cord, use cord as handle, close damaged cord. a door on cord, or pull cord around sharp edges or corners. Do not run this CR2 JR over cord. Keep cord PERIODIC MAINTENANCE away from heated surfaces. -
Page 7: Machine Layout-Rear
REAR OF MACHINE OVERVIEW 1. Handle with control switches 2. Vacuum Hose Barb/Recovery Inlet Barb 3. Chemical bottle holder 4. Chemical intake hose 5. Power cord twist lock 6. Priming Valve 7. Blow hose connector 8. Pressure regulator 9. Quick Disconnect for solution hose 10. -
Page 8: Included Accessories
Hand Squeegee Used to remove excess liquid from smooth verti- cal surfaces. 8. Part # J13975 Faucet Adapter. Presses on to most standard fau- cets to easily fill the CR2 JR without using buck- ets. 9. *NOT SHOWN- ACCESSORY MESH... -
Page 9: Installing Metering Tips
11511A INSTRUCTIONS INSTALLING METERING TIPS Step 3. 6” CLEAR Thread the appropriate tip onto the threaded side of HOSE the hose barb. HOSE BARB WITH THREADED Step 4. Reinsert the threaded barb with tip into the 6” clear hose . Step 1. -
Page 10: Assembling The Accessory Racks
USING 9000AC -1 HIGH PRESSURE GUN : ASSEMBLING THE ACCESSORY RACKS: The CR2 JR is shipped with the accessory racks and hard- ware in the solution tank. When you receive your CR2 Use the spray tip collar to select between low pressure JR, it is necessary to secure the racks to the body. -
Page 11: Recovering Liquid From Hard Surfaces
CLEANING CARPET OR UPHOLSTERY: 7. Turn the chemical dispensing valve to the left to- ward the word “SOAP”. The CR2 JR can be used as a non-heated carpet ex- 8. Chemical will draw Accurately only in the “LOW” tractor. pressure setting of your pressure gun. To activate the “LOW”... -
Page 13: Upper Assembly Breakdown
2700RC UPPER 4.12.2023 ITEM NO. PART NUMBER DESCRIPTION QTY. 10989-2A BALL FLOAT 14591 ACCESSORY BAG A00052 90 DEGREE ELBOW, .25" MP X .25" FP A00060 BARB, .375" X .25" MPT, BRASS A00124 LOCKNUT, .25NPT, BRASS A00163 NIPPLE, 1/4" NPT, 3" LENGTH A12964 COUPLER, .25", BRASS A90004... - Page 14 2700RC UPPER 4.12.2023 ITEM NO. PART NUMBER DESCRIPTION QTY. F11787-1-RC SOLUTION TANK, GRANITE GREY F11788-1 RECOVERY TANK, GRANITE GREY F11791-1 SOLUTION LID, GRANITE GREY J00650 SCREW CLAMP #24 1.25 INCH K00665-1 HOSE ADAPTER 1.5" K00666 90 DEGREE ELBOW K00672 PVC PIPE, 1.5" SCH40, 1.3125' K00672-1 PVC PIPE, 1 1/2"...
-
Page 16: Lower Assembly Breakdown
2700RC BASE 4.12.2023 ITEM NO. PART NUMBER DESCRIPTION QTY. 00580-10IN-FF-A HOSE ASSEMBLY, 10" x 1/4" NPT, F-F 00580-10IN-MF-A HOSE ASSEMBLY, .25" MP X .25" FP, 10" L 00580-35IN-MM-A HOSE ASSEMBLY, .25" MP X .25" MP, 35" L A00052 90 DEGREE ELBOW, .25" MP X .25" FP A00053 45 DEGREE ELBOW, .25"... - Page 17 2700RC BASE 4.12.2023 ITEM NO. PART NUMBER DESCRIPTION QTY. D13347 BRACKET D13620 PLATE, REGULATOR D13684 BRACKET, WAND D13697-3 RACK, SOL. HOSE/POWERCORD E00449 GROMMET E11128 DRAIN VALVE GASKET E11169 GASKET, VACUUM MOTOR E13867 SANDWICH MOUNT, NEOPRENE E14629 GASKET, VACUUM PLATE F11178-1 INTERCOOLER, SINGLE PORT F11789-1-RC CR2 BASE, GRANITE BLUE...
