- Page 1 GET IE DONE ! 10 WET SHARPENER " Contact Us: email: service@bucktool.com https://www.bucktool.com IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety MANUAL Guidelines and Operating Instructions before operating this product.
-
Page 2: Table Of Contents
SCM8101 TABLE OF CONTENTS Specifications Safety guidelines Package contents Key parts diagram Operating instructions Maintenance Exploded view Parts list Troubleshooting Warranty SPECIFICATIONS Motor 230~240V, 50Hz , 180W Wet Wheel size 250x50x12mm 220# Stropping wheel size 200x30x12.5mm Wheel speed 95RPM... - Page 3 SCM8101 IMPORTANT! Safety is the single most important consideration in the operation of this equipment. The following instructions must be followed at all times. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury.
- Page 4 SCM8101 2) Electrical safety a. The terminal plug of the tool must fit into the outlet. The plug may not be modified in any way. Do not use an adaptor plug together with grounded power tools. The original plugs and the appropriate outlets reduce the risk of an electrical shock.
- Page 5 SCM8101 4) Use and treatment of the power tool a. Do not overtax the tool. Use the appropriate tool for the work that is to be done. With the correct power tool, you can work better and more safely. b. Do not use a power tool where the switch is defective. A power tool that cannot be turned on and off is dangerous and must be repaired.
-
Page 6: Package Contents
SCM8101 Package contents No. Description Qty. Sharpener Universal support Grinding jig Wet Grinding wheel Water reservoir Bolt Flat washer Angle guide Honing compound Sharpening stone Wrench Short knife jig Figure 3... - Page 7 SCM8101 Description Qty. Horizontal mounts with knobs Universal support Leather stropping wheel Vertical mounts with knobs On/off switch Water reservoir Grinding wheel Knife holder Figure 4...
- Page 8 SCM8101 Placement See Figure 5 for the minimum working 17" clearances. Remember that the sharpener has no specific front or back side and must be repositioned depending on the desired grinding/sharpening/honing action. 20" Figure 5 Mount The Wet Stone The sharpener is shipped with the Wet Stone off of the machine. Make sure that the machine is not plugged in before assembling the stone onto the sharpener.
- Page 9 SCM8101 Grinding Tips Always be sure the grinding wheel is wet before grinding by having the reservoir filled and in the proper location. Wear the proper protective clothing. Safety glasses/face shield and a dust mask should be worn at all times.
- Page 10 SCM8101 GRINDING WITH WHEEL ROTATION DISCONNECT SHARPENER FROM POWER! Position the machine with the ON/OFF switch facing away from you. Attach the universal support in the horizontal ttach the universal support in the horizontamounts as shown in Figure 7. Be sure it is securely positioned and will not move during grinding.
- Page 11 SCM8101 Water Reservoir Fig. 2 Fig. 5 The wet sharpener is designed for wet grinding and should never be used without water. The mounting tabs on the reservoir serve as hooks to attach to the reservoir mounting slots. Figure 9 to just below the V-shaped notch.
- Page 12 SCM8101 Angle Guide he shar ener comes with an an le uide to hel identify and maintain the cuttin an le on a variety of tools 1. Mount the blade in the Grinding Jig and place the support arm in the mount.
- Page 13 SCM8101 Fig. 1 Fig. 4 Sharpening The leather stropping wheel on the sharpener and the included abrasive stropping paste can be used to obtain a razor sharp edge on many tools. Before use, the stropping wheel must be properly prepared.
-
Page 14: Maintenance
SCM8101 MAINTENANCE Grinding Wheels The grinding wheel should be inspected before every use. Take care in storing grinding wheels to keep them free from potential damage from moisture, from being dropped, or from having other items drop on them. Wheel Replacement... - Page 15 SCM8101...
- Page 16 SCM8101 Item Description Item Description Grinding jig Base assy F-Support Rubber foot Philips screw M5x16 Philips screw M6x16 Motor assy Handle Philips screw M8x35 Philips screw M4x8 Strain relife Worm gear case cover Wire connection box Nut M12 Capacitor Flange...
-
Page 17: Troubleshooting
SCM8101 TROUBLE SHOOTING SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Check power source for proper Low voltage. voltage. Inspect all connections on motor Open circuit in motor Motor will not start. for loose or open connections. or loose connections. (Send for Servicing.) Blown fuse or breaker. - Page 18 GET IT DONE ! NOTE:...
- Page 19 Through a combination of years of hard work and experience we’ve been able to bring you the BUCKTOOL brand you see today. We live for challenges and strive to make our customers 100% satisfied. What BUCKTOOL does for customers is special, and we want to share this with you.
-
Page 20: Warranty
GET IT DONE ! TWO-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : service@bucktool.com https://www.bucktool.com https://www.bucktool.com...
