Brunner Urfeuer 50 Installation Manual

Kitchen fireplace

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation

Guide

Urfeuer 50/66

Kitchen fireplace

Table of Contents

Need help?

Do you have a question about the Urfeuer 50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Brunner Urfeuer 50

Page 2: Table Of Contents
Drawings and technical data.................. 30 Replacement for the chapter 'In the radiant area of the fireplace insert' from 'General construction infor- mation" of the Brunner products ment for the stove fitters': In the radiation area of the Urfeuer fireplace Parts made of flammable building materials or with...
Page 3: Basic Information
Please notify your supplier of any damage which might have occurred during transport.Please keep these in- structions. Please also take note of the online product documentation provided General instructions of the Brunner products installation for the stove construction. (https://www.brunner.de/Allgemein/Allgemeine_Hin- weise_für_den_Aufbau_en.pdf) ©...
Page 4: Product Description
The external surfaces are getting hot. Do not touch - risk of burns! Remember to warn your children about this. Basically, children should stay away from a burning stove. For operation use always the attached operating tool! Fire hazard Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 5: Delivery Contents
The basic device is delivered preassembled on a pallet. The combustion chamber linings are attached as a separate packing unit. Other components (combustion chamber extension plates, mounting frame, etc.) are delivered in further packing units. © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 6: Assemblies
ASSEMBLIES Overview A Kitchen fireplace front complete B Fireplace extension for C Complete mounting frame assembly grilling Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 7 N006095 Skewer L66 D015012 Spark mesh guide assembly Revision cover for counter- D020082 weights Body - Part 1 Item Part No. Designation Pcs. Item Part No. Designation Pcs. © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 8 Body Part 2 Item Part No. Designation Pcs. Item Part No. Designation Pcs. D015096 250mm blind cover N006099 Skewer fork short N006100 Skewer fork long D015625 Opposite side holding plate Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 9 Pulley plate assembly D60 2000467 Spark mesh counterweight wire I003247 Guide roller mounting as- D015259 Spark mesh counterweight sembly right side I001149 Bottom door stop I003212 Guide roller mounting assembly left side © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 10 D015115 Shut-off flap linkage part 1 800257 Hexagon screw M8x40 800386 Hexagon nut M8 800453 Fork head D023040 Shut-off reversing lever assembly D023042 Signal pin 900826 Spring clip with groove 8x32 Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 11 Fire protection plate 1 D015621 Fire protection plate 3 grill spike D015091 Cast iron fireplace bottom plate 2 D015005 Cast iron fireplace bottom plate 1 D015018 Fireplace bottom spacer © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 12 Pcs. D015165-03 Combustion chamber lining 3 D015003 Combustion chamber lining 2 D015027 Combustion chamber lining 1 D015165-02 Combustion chamber lining 3 00328 Hexagon screw M8x25 800386 Hexagon nut M8 Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 13 Hexagon screw M5x16 800002 Hexagon nut M5 Mounting frame Item Part No. Designation Pcs. D015011-02 Mounting frame 00947 Sheet metal nut 800529 Lens flange screw M5x20 01836 Countersunk screw M5x16 © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 20: Assembly Of Combustion Chamber
ASSEMBLY OF COMBUSTION CHAMBER Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 26: Assembly Of Deflector Plate
ASSEMBLY OF DEFLECTOR PLATE INSERT THE GRILL GRATE Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6) © 2020 Brunner GmbH...
Page 27: Remove The Grill Motor
If necessary, the grill motor can be removed and replaced at any time from the side of the combustion cham- ber. Proceed as following: (in the picture is shown a Urfeuer kitchen fireplace with function niche). © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)
Page 30: Drawings And Technical Data
Dimension sheets - Urfeuer® 50/66 Küchenkamin … with mounting frame … mounting frame Stand: 2020-09-23...
Page 31 Dimension sheets - Urfeuer® 50/66 Küchenkamin … with functional niche We suggest for CAD planning Palette CAD. Permanent updated drawings: www.brunner.de Frames /flue gas outlet connection/ combustion air supply connection/ front variants are marked in color. Stand: 2020-09-23...
Page 32 Planning and installation - Urfeuer® 50/66 Küchenkamin Tested according to EN 13229 W 53.5 Data for functional demonstration Flue gas mass flow Flue gas temeperature °C Necessary supply pressure Total fuel load 2 - 4 Combustion air consumption Combustion air connection Ø Cross-section of gratings Convection air Supply air...
Page 33 Ulrich Brunner GmbH Zellhuber Ring 17-18 D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 Fax: +49 (0) 8721/771-100 Email: info@brunner.de Art. No.: XXXXX © 2020 Brunner GmbH Installation Guide Urfeuer 50/66 Kitchen fireplace (1.6)

This manual is also suitable for:

Urfeuer 66
