Xylem GOULDS AQUAFORCE e-HVX Quick Manual

1 Introduction
NOTICE:
Read the installation, operation and maintenance instructions located
on the Xylem website before use. Improper use of the product can
cause personal injury and damage to property and may void the war‐
ranty. See e-HVX/e-HVXR Booster System Instruction Manual for com‐
plete Product Warranty.
WARNING:
Personal protective equipment should be worn when
handling this equipment. Only use properly sized certi‐
fied lifting equipment & lifting devices, including slings,
suitably rated for the weights to be lifted. Slings, when
used, must be of identical materials to avoid differences
in stretch rates. Do not use lifting devices that are frayed,
kinked, unmarked, or worn.
2 Transportation requirements
WARNING:
• Assembled units and their components are heavy.
Failure to properly lift and support this equipment
can result in serious physical injury and/or equip‐
ment damage. Lift equipment only at the specifical‐
ly identified lifting points. Lifting devices such as
eyebolts, slings, and spreaders must be rated, se‐
lected, and used for the entire load being lifted.
• Crush hazard. The unit and the components can be
heavy. Use proper lifting methods and wear steel-
toed shoes at all times.
CAUTION:
Care should be taken to prevent damage due to drop‐
ping or jolting when moving the controller. Transporta‐
tion damage should be brought to the carrier's attention
immediately upon receipt.
AQUAFORCE e-HVX & e-HVXR
Variable Speed Pumping Systems
For safety and correct product usage, read the manual before this
product is used.
WARNING:
Always lock out power to the driver before you perform
any installation of maintenance tasks. Failure to discon‐
nect and lock out driver power will result in serious injury.
WARNING:
This product can expose you to chemicals including
Lead, which is known to the State of California to cause
cancer and birth defects or other reproductive harm. For
more information go to: www.P65Warnings.ca.gov.
Lifting and handling instructions
NOTICE:
Eyelets located on the motors must not be used to lift the entire packaged sys‐
tem unit.
1. Remove packing materials from the product.
2. Release the pump set from the pallet by removing the screws and /or cutting
the straps.
QUICK GUIDE
IM431_Rev A
THE MANUAL IS AVAILABLE AT:
https://qr.xylemsales.com/ocmx80
