R volution PlayerOne 8K Quick Start Manual page 9

Remote Control
1. LIGHT: Turn on the backlight of the remote control.
2. POWER: Toggle power ON/OFF .
3. TV SECTION:
Programmable buttons to control TV or other
external device.
4-5. POWER ON/OFF: Discrete power ON/OFF.
6. DIMMER: Toggle front LED screen ON/OFF .
7. DELETE: Delete the previously entered character.
8-9. PREV/NEXT: Go to the previous/next chapter.
10. ZOOM: Zoom In / Out (overscan).
11-12. -60/+60: Timeline navigation (-/+ 60 sec.).
13-14. -10/+10: Timeline navigation (-/+ 10 sec.).
15. MODE : Safe video mode.
16. < >: Go to playback position.
17. STOP: Stop video playback.
18. PLAY/PAUSE: Start / Pause playback.
19-20. UP: Next file (Explorer). DOWN: Previous file (Explorer).
21-22. LEFT/RIGHT: Timeline navigation (-/+1 min).
23. HOME: Go to Main Menu (Home Page).
24. MOUSE: Switch to the virtual mouse mode.
25. MENU: Show / Hide the pop-up menu.
26. BACK: Return or Stop playback.
19-22. ARROWS: Navigate menu selection.
27. OK: Enter or validate the current item.
Long-press : show the on-screen playback menu.
28-29. VOLUME +/-: Increase / Decrease volume.
30. REPEAT: Repeat playback (file, all, off).
31. INFO: Show / Hide the pop-up info (properties).
32-33. PAGE+/-: Timeline navigation.
34. R_VIDEO: R_video shortcut.
35. MUTE: Mute audio.
36. EXPLORER: R_volution Explorer shortcut.
37. NUMBER Buttons:
- 1-9: direct access to 10 - 90% (video playback or movie list).
- 0: Restart from the beginning (video playback or movie list).
38. SUBTITLE: Subtitle switch.
39. AUDIO: Audio track switch.
40. RED (A): Contextual shortcut.
41. GREEN (B): Contextual shortcut.
42. YELLOW (C): Contextual shortcut.
43. BLUE (D): Contextual shortcut.
Using the Remote Control
60°
When using the remote control, the front
window of the remote control should be
pointed to the infrared sensor on the front
panel within an angle of ±60° and a range
of about 26 ft.
Please use alkaline batteries.
Please observe polarity when inserting batteries.
1
4
6
7
11
10
15
16
19
23
21
25
20
28
31
29
34
38
Within about
26 ft (8m)
Third Party Control
You can control your R_volution
player using third party devices
such as Control4, Crestron, RTI,
ProControl, Savant, Logitech, Elan...
More info:
rvolution.com/knowledgebase
7
2
3
5
8
9
12
13
14
17
18
24
27
22
26
32
30
33
35
36
37
39
43
42
41
40
