R volution PlayerOne 8K Quick Start Manual page 8

6
2
3
1. LCD Screen
2. POWER ON/Sleep
1
2
1. Wi-Fi Antenna
2. USB 3.0 Host
3. IR IN (IR extenter included)
4. Optical Digital Audio Output
5. Analog Audio Output / Restore
6. HDMI 2.1a Output
Front View
1
4
3. USB 2.0 Host
4. Power LED 5. Internal Hard Drive Rack Door
Rear View
12
3 2 4 5 6 7 8
5
9
7. LAN 10/100/1000 (Ethernet)
8. DC Input for External Power Supply 12V ≥3A
9. Ground
10. Power ON/OFF
11. Power Input
12. RF Antenna
1
10 11
