ENFORCER VC-3YAQ Installation Manual

4-in-1 HD to HDMI Converter
VC-3YAQ
Installation Manual
The ENFORCER 4-in-1 HD to HDMI Converter transforms HD-TVI, HD-CVI, HD-AHD, or
traditional analog video inputs into an HDMI, VGA, or CVBS signal. The converter also allows for
HD analog video loop output, HD analog dual video input, and picture-in-picture modes. The
converter is compact and can be mounted nearly anywhere and is a good solution for converting
any HD analog video source to an HDMI, VGA, or CVBS signal to allow viewing on a wide range of
video monitors.
 Converts HD-TVI, HD-CVI, HD-AHD, or analog/CVBS video to HDMI, VGA, CVBS, or
loop output
 Secondary BNC connection supports CVBS conversion, loop output, or dual HD analog
video input
 Dual HD Analog video input mode to switch between multiple video inputs
 Wall mountable with included screws
 Picture-in-picture mode when dual HD analog video input used
 HDMI/VGA output support: 480p, 576p, 720p, 1080i, 1080p
 CVBS output support: NTSC, PAL
 CVBS underscan adjustment
 Compact, perfect for plug and play installations
 Quick installation, no driver or operating system requirements
