ST-LA108-TPQ
ST-LA115-TPQ
Model
ST-LA108-TPQ
Input
16~28 VAC/VDC
voltage
Output
voltage
Output
0.8A
current
Power Converters
Manual
ST-LA115-TPQ
18~28 VAC/VDC
12VDC
1.5A
®
ST-LA130-TTQ
ST-LA130-TTQ
18~24 VAC/VDC for 12VDC
24~28 VAC or 26~28 VDC for 24VDC
12/24 VDC
3A@12VDC
1.5A@24VDC
Advertisement
Related Manuals for ENFORCER ST-LA108-TPQ
Summary of Contents for ENFORCER ST-LA108-TPQ
- Page 1 Power Converters Manual ST-LA108-TPQ ST-LA130-TTQ ST-LA115-TPQ Model ST-LA108-TPQ ST-LA115-TPQ ST-LA130-TTQ Input 18~24 VAC/VDC for 12VDC 16~28 VAC/VDC 18~28 VAC/VDC voltage 24~28 VAC or 26~28 VDC for 24VDC Output 12VDC 12/24 VDC voltage Output 3A@12VDC 0.8A 1.5A current 1.5A@24VDC ®...
- Page 2 Regulated and filtered output Green LED indicates power input Red and Blue LEDs indicate power output (ST-LA130-TTQ only) ST-LA108-TPQ and ST-LA115-TPQ Only: 2.1mm DC Plug with pigtail for simple and quick installations Dimensions: ST-LA108-TPQ and ST-LA115-TPQ...
- Page 3 2. Connect power to the input side terminal block. Polarity is not important. For the ST-LA108-TPQ, connect a 16~24 VAC/VDC power supply. For the ST-LA115-TPQ, connect an 18~24 VAC/VDC power supply. Note: Do not turn on the power supply until ready to test.
-
Page 4: Specifications
ENFORCER Power Converters Specifications: Model ST-LA108-TPQ ST-LA115-TPQ ST-LA130-TTQ Input Terminal block connector Output 2.1mm DC Plug Terminal block connector Input 18~24 VAC/VDC for 12VDC 16~28 VAC/VDC 18~28 VAC/VDC voltage 24~28 VAC or 26~28VDC for 24VDC Output 12VDC 12/24 VDC voltage...
