- Page 1 ASSEMBLY INSTRUCTIONS OTTO rectangular dining table...
- Page 2 ASSEMBLY INSTRUCTIONS RECTANGULAR TRAVERTIN TABLE CONTENT Travertin table top Base Frame 16 x Bolt M6 Bumpon Wrench...
- Page 3 Place both bases upright and align them with each other by using the supplied cardboard jig. Make sure the holes in the cardboard match with the holes in the bases To place the cardboard jig, fold the side flaps down so it becomes rigid and straight.
- Page 4 Remove the cardboard jig and place the frame on the bases, so the holes of both parts are aligned. Mount the frame against the bases by screwing 4 bolts through each base.
- Page 5 Place bumpons on top of the table frame, divided as shown below. Remove the liner and adhese the bumpon to the frame. Make sure the bumpons are 0.5 cm away from the edge. Place the travertin table top over the frame. After this, the table is assembled and ready to use Ensure that the weight is evenly distributed along the long side...
- Page 6 ASSEMBLY INSTRUCTIONS RECTANGULAR CERAMIC TABLE CONTENT Ceramic table top Base Bolt M6 Wrench...
- Page 7 Place both bases upright and align them with each other by using the supplied cardboard jig. Make sure the holes in the cardboard match with the holes in the bases. To place the cardboard jig, fold the side flaps down so it becomes rigid and straight.
- Page 8 Place the ceramic top on both bases. Make sure the holes of the bases are aligned with the inserts in the ceramic top. Ensure that the weight is evenly distributed along the long side when lifting the top. Lift with +4 persons.
- Page 9 Mount the ceramic top against the bases by screwing the 8 bolts through the bases, inside the inserts of the ceramic top (4 bolts for each base). After this the table is assembled and ready to use.
- Page 10 04254-CX 04253-TV Tribù nv Oude Heidestraat 72 3740 Bilzen BELGIUM www.tribu.com info@tribu.com...
