Control Data 1700 Maintenance Manual page 7

TABLE OF FIGURES
&
TABLES
FIGURES
Figure 5-1
Card Reader Timing Chain
5-4
TABLES
Table A
Low Speed Station Codes
vii
Table 2-1 Teletypewriter ASCII Code
2-4
Table 2-2 Teletypewriter Status Code 2-6
Table 2-3 1711/1712 Function Code Bit Significance 2-11
Table 2-4 1713 Function Code Bit Significance 2-12
Table 2-5 TTY Timing Chain Events for Read
2-19
Table 2-6 TTY Timing Chain Events for Write 2-25
Table 3-1 P. T. Reader Function Codes
3-1
Table .3-2 P. T. Reader Status Codes
3-2
Table 4-1
P. T. Punch Function Codes
4-1
Table 4-2 P. T. Punch Status Codes 4-2
Table 5-1 Card Reader Function Codes
5-1
Table 5-2 Card Reader Status Codes 5-2
Table 5-3 Card Reader Timing Chain Cycle 5-4
