- Page 1 Springtree Media Group User Manual The Spartan300-RGBAL...
- Page 2 Table of Contents Description Specifications DMX Traits Menu Operation Installation Safety & Troubleshooting Contact Us...
- Page 3 Springtree Media Group Description The Spartan300-RGBAL The Spartan300-RGBAL is a 300Watt, Full Color LED Fresnel with a comparable output to a traditional 750Watt incandescent Fresnel. Springtree Fresnels create a soft and even wash of light with a smooth transition between the center and the edges of the beam, resulting in a gentle and uniform illumination across your stage.
- Page 4 Springtree Media Group Specifications Optical Connections Light Source: 300Watt COB LED 3-pin DMX In/Out RGBAL 5-in-1 Linking Power Cord In/Out Beam Angle: 15 – 50° Color Rendering Index: > 95 Included LED Refresh Rate: 10 kHz 1x Spartan300-RGBAL 1x Bracket...
- Page 5 Springtree Media Group DMX Traits 6 Channel Mode 5 Channel Mode Dimmer 0~255 0~255 0~255 Green 0~255 Green 0~255 Blue 0~255 Blue 0~255 Amber 0~255 Amber 0~255 Lime 0~255 Lime 0~255 7 Channel Mode Dimmer 0~255 0~255 Green 0~255 Blue...
- Page 6 Springtree Media Group Menu Operation Value Description Function ADDR DMX Address d001~d512 CH-M Channel Mode 5CH, 6CH, 7CH MENU Dimmer Dimm 0~255 MENU Strobe Flas 0Hz~30Hz MENU Red Intensity 0~255 MENU Green Intensity 0~255 MENU Blue Intensity 0~255 Amber Intensity...
- Page 7 Springtree Media Group Menu Operation Value Description Function Line DIMC Dimmer Curve LED (quick off) DRES Dimmer Resolve Lamp (fade out) Version TEMP Temperature Reset to Default RSET Settings The Spartan300-RGBAL...
- Page 8 Mounting Position the Spartan300-RGBAL in any orientation that allows ample room for ventilation. Operating the device in a poorly ventilated space can result in overheating and pose serious safety risks. Maintain a minimum distance of 6- inches around and above the device to ensure proper airflow.
- Page 9 Springtree Media Group Safety 1. Do not expose this unit to moisture to reduce the risk of electrical shock or fire. 2. Be sure that the local power outlet matches the required voltage for your unit. 3. Do not attempt to operate this unit if the power cord has been frayed or broken.
- Page 10 We Are Here For You! Springtree is all about simplifying the AV process. A big part of that is being available to answer your questions. Give us a call or fill out a contact form. We are here to help! Contact Us springtree.net/contact-us/...
