Chapter 1 Introduction; Product Specifications - CHAINTECH 9BIF3 Manual

1-1 Product Specifications

r r r r r Processor
- Supports Intel Pentium 4 Socket 478 processors
- Support system bus at 400/533MHz (Brookdale-G)
- Support system bus at 400MHz (Brookdale-GL)
r r r r r Chipset
- Intel optional Brookdale-G or Brookdale-GL + ICH4 chipset
r r r r r DRAM Memory
- Two 184-pin DDR DIMM sockets support up to 2 GB
- Supports PC-1600/2100 DDR SDRAM Modules
r r r r r Expansion Slots
- One AGP slot for 4XAGP at 1.5v (v2.0 compliant) or optional LTI2-845G
adapter supports DVI and NTSC/PAL TV system (Brookdale-G)
- One AGP slot exclusively for optional LTI2-845G adapter supports DVI and
NTSC/PAL TV system only (Brookdale-GL)
- Three 32-bit PCI slots (Rev 2.2 compliant)
- One CNR slot for modem, audio and LAN riser
Brookdale-G chip support only 1.5v AGP electricals. VGA card using 3.3v
or other voltages may result in system boot up failure, malfunction, etc.
r r r r r Boot-Block Flash ROM
- Phoenix-Award BIOS, supports PnP, APM, DMI, ACPI & Multi-device booting
features i.e. floppy, LS120, CD/DVD-ROM, HDD(IDE, SCSI), ZIP-ATAPI etc.
r r r r r Embedded Ultra DMA-100 PCI IDE controller
- Supports two IDE ports up to 4 ATAPI devices
- Supports up to PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 66MBps
and Multi Word Mode 5 up to 100MBps with bus mastering
- Bus Mastering software drivers for common multi-task operating systems
r r r r r On-board Super I/O Controller
- ITE 8712 LPC with system monitoring hardware
- Two UARTs support two serial ports and IR function for HPSIR and ASKIR
- One parallel supports SPP/ECP/EPP
- One floppy disk drive connector supports up to 2.88MB
- Integrated smart card reader function and interface
r r r r r
Embedded System Monitor Hardware
- 8 external voltage inputs
- 1 temperature sensor with thermistor for CPU and System
