Intended Use

The X40 System is designed for the purpose of inspecting pipelines of all kinds. This
lightweight push-rod camera inspection system is designed to provide both the flexibility to
navigate tight bends and traps, whilst being strong enough to be pushed the distance in
abrasive pipes. With an ultra-flexible spring-bound camera head and a tough but flexible
push-rod, this product will navigate around 90deg bends and beyond.
Any other use deviating from or exceeding this purpose is deemed as misuse. In the event of
misuse, the manufacturer declines any responsibility and shall not be held liable for any
warranty or other claim whatsoever.
Warning:
The X40 System is not designed for use in mines susceptible to firedamp, nor in
hazardous areas with explosive dust atmospheres. Surveys or inspections where
these hazards are present are prohibited.
Warning:
Operators should remain aware of their surroundings and any other sources of
danger while undertaking CCTV inspections or surveys, such as plant or heavy
construction equipment movements, exposed electrical installations, exposed
earthworks, excavations, etc.

About Your X40 System

The X40 System has been designed as a CCTV pipeline survey and inspection system and is
suitable for use in non-hazardous locations. It consists of 40 meters of flexible pushrod with
a robust outer jacket and a camera head designed to negotiate several tight bends within
pipe sizes varying from 50mm up to 150mm. The X40 can be controlled using a Maxprobe™
CCU and iOS/Android devices, with a traceable 30mm TrapJumper camera head using a
frequency magnetic sonde. The X40 System is designed to be used from a surface location
outside the pipeline, with the camera head and pushrod being the only components to enter
the pipeline under inspection.
The X40 System coiler has been designed for use on exposed outdoor locations and has a
protection rating of IP56), meaning it can cope with heavy rain and a wash down afterwards.
It is NOT protected against dust ingress and powerful water jets. The Pushrod and Camera
are designed for use in flooded pipelines, drains and culverts, and are completely dustproof
with a rated depth of 3m in standing water (rated to IP68).
By purchasing a X-Range system you are investing in a user-friendly Pipeline inspection
system with outstanding robustness in rough conditions, state-of-the-art technology, and
excellent functionality.

Operating Temperatures

Operating Temperature:
Charging Temperature:
-20°C to +60°C
+10°C to +45°C
