- Page 1 Twin 5 Plus EV Charging Stations Installation and User Manual...
-
Page 3: Table Of Contents
5.5.2 Inserting ground cable and earth cable 5.5.3 Mounting the charging station onto the base Electrical installation Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 5: Safety And Usage Instructions
This manual applies to the Twin 5 Plus (in this document also indicated as “charging station”) produced by Alfen ICU B.V., Hefbrugweg 28, 1332AP Almere, the Netherlands, Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 6: Explanation Of Text Instructions Used
The ACE Service Installer does not notify if a new firmware version is available. You need to check this via the menu “Device/Upload new firmware... ” Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 7: Operating Conditions
Degree of protection (cas- IP54 ing) Firmware informa- tion, update, error IK protection IK10 codes list Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 8: Product Overview
2. PRODUCT OVERVIEW 2.1 Exterior view 220 mm 335mm Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 9: Interior View
2. PRODUCT OVERVIEW 2.2 Interior view Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 10: Legend Product Overview
Figure 2.1: Interior view detail Production date Technical specifications (such as the number of phases, maximum charging current and voltage) Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 11: User Interface
Energy consumed during the current charging session Figure 3.3: Display during charging from both sockets Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 12: Status Indicator Symbols
ON. If the charging station is delivered with a pre-programmed backoffice management system, this functionality will be OFF. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 13: Removing The Master Key
This might, however, incur costs. Therefore, always keep the Master key in a safe location. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 14: Operation
This information is only communicated with the payment. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 15: Finishing The Charging Process With Qr Code
The payment service provider settles the costs of the transaction. An invoice specifying these costs is sent to the email address that was specified earlier. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 16: Start And Stop Charging With Charge Card
Remove the charging cable from the charge point Remove the charging cable from the car Leave the charging place Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 17: Installing And Connecting
IEC 60364 (Electrical Installations for Buildings) standard. Please refer to the following table for safety options and cable cross-sections advised. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 18: Schematic Overview Of Charging Station Protection Devices
The door handle of the charging station can be equipped with 2 locks (depending on scope of delivery): Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 19: Opening The Door With Dummy Key
Place the whole assembly on the 5.3.2 Installation tools bottom of the charging station • Level Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 20: Inserting Ground Cable And Earth Cable
Insert four threaded M10 x 80 mm rods into the sockets on the base. Place the gasket / baseplate assembly over the threaded ends. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... - Page 21 (RCCB) is in the ON (I) position. If a transparent cover is supplied for the internal components, fit it with the bolts supplied. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU...
-
Page 22: Commissioning
Pull out the test charging cable or charging cable. The socket is now ready for use. Repeat the same procedure for the other socket. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 23: Connectivity
Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 24: Before Using The Myeve App
Make sure the firewall settings on your device are not blocking the ACE Service Installer. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 25: Maintenance
Optionally you can find support for all our products on knowledge.alfen.com. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 26: Disposal
recycling center or other collection points. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... -
Page 27: Error Codes And Troubleshooting
RFID- charge point supplier. reader. • Check if RFID-reader is connected correctly. Installation related error Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... - Page 28 TIC charge point supplier. smart energy Meter. • Check TIC smart energy Meter connection. Vehicle related error Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU...
- Page 29 • Check socket and charging cable plug. • Check if the lock motor can move freely. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU...
- Page 30 All cables: No issue with other charge point. Contact the service department of your charge point supplier. Not displayed. Not displayed. Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU...
-
Page 31: Technical Drawings
11. TECHNICAL DRAWINGS Grid Connection Box Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU... - Page 32 11. TECHNICAL DRAWINGS Alfen ICU B.V. | Installation and User Manual | Twin 5 Plus | EV Charging Stations | V1.0 | EN | 03/2024 | 203130253-ICU...
