DEMO MANUAL DC3205A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 4 C1, C7, C9, C18
2 2 C2, C21
3 4 C5, C12, C17, C22
4 2 C11, C23
5 1 C19
6 2 L2, L3
7 1 Q1
8 2 R3, R6
9 1 U1
Additional Demo Board Circuit Components
1 2 C3, C20
2 2 C4, C16
3 2 C6, C14
4 1 C7
5 2 C8, C15
6 1 C10
7 2 C13, C24
8 1 L1
9 2 R1, R10
10 1 R2
11 1 R4
12 1 R5
13 1 R7
14 1 R9
15 1 R11
17 1 Q1
18 0 TP1
Hardware: For Demo Board Only
1 11 E1-E3, E8, E9, E14,
E17-E21
2 6 E4, E7, E10, E15, E16, E22
3 5 E5, E6, E11-E13
4 1 JP1
5 1 JP2
6 4 MP1-MP4
7 2 XJP1, XJP2
8
PART DESCRIPTION
CAP ., 1µF, X7T, 6.3V, 20%, 0201
CAP ., 0.22µF, X7R, 16V, 10%, 0402, AEC-Q200
CAP ., 22µF, X5R, 10V, 20%, 0603
CAP ., 47µF, X6S, 6.3V, 20%, 0805
CAP ., 10pF, C0G/NP0, 25V, 10%, 0402
IND., 220nH, PWR, 20%, 6.7A, 13mΩ, 2.5mm × 2.00mm,
SMD, AEC-Q200
XSTR., MOSFET, N-CH, 30V, 37A, PG-TDSON-8
RES., 100k, 1%, 1/10W, 0402, AEC-Q200
IC, DUAL 2MHz, 4A STEP-DOWN DC/DC REGULATOR
CAP ., 470µF, TANT, POSCAP , 6.3V, 20%, 7343, 18mΩ, TPE PANASONIC, 6TPE470MI
CAP ., 10µF, X7S, 6.3V, 20%, 0603
CAP CER 10µF 6.3V X5R 0402
CAP ., 1µF, X7T, 6.3V, 20%, 0201
CAP ., 0.22µF, X7R, 6.3V, 20%, 0603
CAP ., 0.1µF, X7R, 25V, 10%, 0402, AEC-Q200
CAP ., 1000pF, X7R, 50V, 20%, 0402, 3-TERM, X2Y EMI
FILTER
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A, 6mΩ,
1812
RES., 10k, 5%, 1/16W, 0402, AEC-Q200
RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402
RES., 0Ω, 1/16W, 0402
RES., 1M, 1%, 1/16W, 0402, AEC-Q200
RES., 249k, 1%, 1/16W, 0402, AEC-Q200
RES 0.02Ω 1% 1.5W 1206
XSTR., MOSFET, N-CH, 30V, 37A, PG-TDSON-8
CONN., U.FL, RECEPT, ST SMD, 0Hz to 6GHz 50Ω
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK MILL-MAX, 2308-2-00-80-00-00-07-0
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK MILL-MAX, 2501-2-00-80-00-00-07-0
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218"
CONN., HDR, MALE, 1×4, 2mm, VERT, ST, THT
CONN., HDR, MALE, 1×3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER/PART NUMBER
MURATA, GRM033D70J105ME01D
MURATA, GCM155R71C224KE02D
AVX, 0603ZD226MAT2A
TAIYO YUDEN, JMK212BC6476MG-T
AVX, 04023A100KAT2A
TDK, TFM252012ALMAR22MTAA
INFINEON, BSC011N03LSI
KOA SPEER, RK73H1ETTP1003F
ANALOG DEVICES INC., LTC3314AACBZ-R7
TDK, C1608X7S0J106M080AC
Murata Electronics, GRM155R60J106ME47D
MURATA, GRM033D70J105ME01D
JOHANSON DIELECTRICS, 6R3X14W224MV4T
MURATA, GCM155R71E104KE02D
JOHANSON DIELECTRICS, 500X07W102MV4T
WURTH ELEKTRONIK, 74279226101
NIC, NRC04J103TRF
NIC, NRC04F20R0TRF
YAGEO, RC0402JR-07100KL
VISHAY, CRCW04020000Z0ED
STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
NIC, NRC04F2493TRF
ΩITE, FCSL32R020FER
INFINEON, BSC011N03LSI
HIROSE ELECTRIC, U.FL-R-SMT-1(10)
KEYSTONE, 575-4
WURTH ELEKTRONIK, 62000411121
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 702935000
WURTH ELEKTRONIK, 60800213421
Rev. 0
