TYPICAL PERFORMANCE CHARACTERISTICS
Load Transient Response,
Pulse-Skipping Mode
I
LOAD
5A/DIV
I
L1
5A/DIV
I
L2
5A/DIV
V
OUT
50mV/DIV
LOAD STEP: 0.1A TO 6A IN 1µs
Figure 8. Load Step Response in Pulse-Skipping Mode
with V
= 3.3V
IN
DC3205A F08
10µs/DIV
DEMO MANUAL DC3205A
Load Transient Response,
Burst Mode Operation
I
LOAD
5A/DIV
I
L1
5A/DIV
I
L2
5A/DIV
V
OUT
50mV/DIV
10µs/DIV
LOAD STEP: 0.1A TO 6A IN 1µs
Figure 9. Load Step Response in Burst Mode with V
DC3205A F09
= 3.3V
IN
Rev. 0
