Set-Up
The roller can be adjusted to two different heights.
1. Remove the cotter pins and clevis pins from each side of
the Striper/Roller. See Fig. 1-3.
Cotter Pin
Clevis Pin
Figure 1-3
2. Move the adjustment bracket to the desired height and
replace the cotter pin and clevis pin to lock into place.
Clevis Pin
