Cub Cadet Timing Deck Striper/Roller Operator's Manual

Cub Cadet Timing Deck Striper/Roller Operator's Manual

42" timing deck striper/roller
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
42" Timing Deck Striper/Roller
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-03885
(February 19, 2008)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Timing Deck Striper/Roller and is the answer not in the manual?

Questions and answers

Related Manuals for Cub Cadet Timing Deck Striper/Roller

Summary of Contents for Cub Cadet Timing Deck Striper/Roller

  • Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-03885...

  • Page 2: Assembly And Setup

    Assembly & Set-Up Contents of Carton • One 42” Timing Deck Striper/Roller Assembly NOTE: On older model decks the holes used to attach the Striper/ Roller to the mowing deck will have to be drilled in order to install the attachment.
  • Page 3 Set-Up The roller can be adjusted to two different heights. Remove the cotter pins and clevis pins from each side of the Striper/Roller. See Fig. 1-3. Cotter Pin Clevis Pin Figure 1-3 Move the adjustment bracket to the desired height and replace the cotter pin and clevis pin to lock into place.

  • Page 4: Illustrated Parts List

    Illustrated Parts List Ref. Part Number Description 710-0451 Carriage Bolt, 5⁄16-18 x .750 711-1421 Clevis Pin, 3⁄8 x .750 712-04063 Flange Lock Nut, 5⁄16-18 714-0149B Cotter Pin 726-04035 Push Nut, 3⁄4 731-0335 Deck Roller 731-06365 Deck Roller, 2.25 x 5.25 736-0188 Flat Washer, .76 x 1.49 x .06 736-3024...
  • Page 5 Notes...
  • Page 6 Otes...
  • Page 7 Otes...
  • Page 8 To order replacement parts, call a Customer Support Representative at (800) 965-4CUB. Locate your nearest Cub Cadet dealer at (877) 282-8684 or visit www.cubcadet.com to find the nearest Cub Cadet dealer in your area. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019...
