distributor (part
number
03-0050).
Your
cabinet
may
already contain
this
bracket.
When
installing, the
bracket should be
mounted
inside
the coin
door and on
top of the cashbox
for easy
access.
NOTE:
The
A-cartridge also contains the
same
Test
and
Volume
functions
found on
the
test
bracket.
Wiring of
the
Test Bracket
requires connections
to
both
the
main
JAMMA
harness
as well as the Auxiliary Cable
harness
(refer to
Table
3).
LEAD WIRE
COLOR
SWITCH
FUNCTION
CONNECTS
TO
YELLOW
VOLUME-UP
AUX.
CABLE
'29'
(GRAY/
YELLOW)
GREEN
COMMON
AUX.
CABLE
'31
'(BLACK/
WHITE)
BLACK
VOLUME-
DOWN
AUX.
CABLE
'30' (PINK/
YELLOW)
GREEN
COMMON
AUX.
CABLE
'31
'(BLACK/
WHITE)
BROWN
TEST
JAMMA
'15'
BLACK GROUND JAMMA
'A'
or
'B' or
'e'
or
'for
Tor
'2'
or
'27'
or
'28'
Table
3:
Test Bracket Wiring
Chart
Game
Cartridge
Installation
21.
Install
the four
(4)
mounting
brackets
to the
underside of
the
"A"
cartridge as
shown
in
Figure
7.
Figure
7:
Mounting
Bracket
Installation
22.
Using
the supplied
wood
screws, fasten the
game
cartridge
case
to the control panel
shelf,
as
shown
in
Figure
8.
f
23.
Connect
the
JAMMA
harness connector
and
the
Auxiliary Cable
connector
to the
"A'
cartridge.
If
your
cabinet
is
equipped with
Q-SOUND,
also attach
the
audio
cables.
Proprietary
and
confidential information, not
to
be
disclosed
or copied without
the express permission of
CAPCOM®
COIN-OP,
INC.'
