Control Panel Buttons
and
Switches
15.
Notice
that there
are
two
white
buttons. (See
Figure
3.) Install the
PLAYER ONE
button
on
the
top
left-hand side of
the control panel,
and
the
PLAYER
TWO
button
on
the top right-side of the control panel.
The
WHITE
buttons are
START
buttons.
FIGURE
3
Function
and
Start
Buttons
16. Install the
switched on
the buttons as
shown
in
Figure
2.
Orient the switches so
that
when
a button
is
pressed, the
red contact on
the switch
is
depressed.
17. Install
the joysticks
on
the control panel
as
shown
in
Figure
4.
Wiring
NOTE:
All switch wires used
in this
game
must
be wired
to
the
normally-open connection on
the switches.
Each
switch
requires
a
ground
wire
on
the
common
connector and
the appropriate control or switch wire on
the normally-open connector of
the switch.
18.
Reconnect
the existing
JAMMA
connectors
to the
control panel
according
to
Table
1.
19.
Connect
the Player
1
and
Player 2
buttons
to the
auxiliary cable harness connectors
shown
in
Figure
5.
Make
the connections according
to
Table
2.
