Manual
DF comfort 10
Content & general information
top profile
side channel
DIN 7981 Ø3,9
x 16 mm for
wooden and
synthetic
windows
Mounting of the pleated blind
1
Join the 2 side channels and the top profile.
www.diaz.be
pleated blind
handle
The older window model
GGU with 105° mortise
requires the spacers
supplied to be inserted into
the running rail. Place the
spacers near the screw.
1
Advertisement
Table of Contents
Related Manuals for Diaz DF comfort 10
Summary of Contents for Diaz DF comfort 10
- Page 1 Manual DF comfort 10 Content & general information top profile The older window model GGU with 105° mortise requires the spacers supplied to be inserted into side channel the running rail. Place the spacers near the screw. pleated blind DIN 7981 Ø3,9...
- Page 2 Tighten the screws again. Mount the operation handle. Slide the handles onto the adapter. Remove rubber band and unwind the cord incl. the tensions cord bracket. cord tension cord bracket rubber band www.diaz.be...
- Page 3 Adjustment of the cord tension must be uniform and can only be done by a professional. Operation of the pleated blind The DF comfort 10 is opened and closed by moving the operation handle, using the control rod if necessary www.diaz.be...
